IMS OneRoster Resources Service Version 1.2

IMS Candidate Final Public
Version 1.0

Date Issued: 1st July 2021
Latest version: http://www.imsglobal.org/activity/onerosterlis/

IPR and Distribution Notices

Recipients of this document are requested to submit, with their comments, notification of any relevant patent claims or other intellectual property rights of which they may be aware that might be infringed by any implementation of the specification set forth in this document, and to provide supporting documentation.

IMS takes no position regarding the validity or scope of any intellectual property or other rights that might be claimed to pertain to the implementation or use of the technology described in this document or the extent to which any license under such rights might or might not be available; neither does it represent that it has made any effort to identify any such rights. Information on IMS's procedures with respect to rights in IMS specifications can be found at the IMS Intellectual Property Rights web page: http://www.imsglobal.org/ipr/imsipr_policyFinal.pdf.

Copyright © 2021 IMS Global Learning Consortium. All Rights Reserved.

Use of this specification to develop products or services is governed by the license with IMS found on the IMS website: http://www.imsglobal.org/speclicense.html.

Permission is granted to all parties to use excerpts from this document as needed in producing requests for proposals.

The limited permissions granted above are perpetual and will not be revoked by IMS or its successors or assigns.

THIS SPECIFICATION IS BEING OFFERED WITHOUT ANY WARRANTY WHATSOEVER, AND IN PARTICULAR, ANY WARRANTY OF NONINFRINGEMENT IS EXPRESSLY DISCLAIMED. ANY USE OF THIS SPECIFICATION SHALL BE MADE ENTIRELY AT THE IMPLEMENTER'S OWN RISK, AND NEITHER THE CONSORTIUM, NOR ANY OF ITS MEMBERS OR SUBMITTERS, SHALL HAVE ANY LIABILITY WHATSOEVER TO ANY IMPLEMENTER OR THIRD PARTY FOR ANY DAMAGES OF ANY NATURE WHATSOEVER, DIRECTLY OR INDIRECTLY, ARISING FROM THE USE OF THIS SPECIFICATION.

Public contributions, comments and questions can be posted here: www.imsglobal.org/forums/ims-glc-public-forums-and-resources.

Trademark information: http://www.imsglobal.org/copyright.html

Document Name: IMS OneRoster Resources Service v1.2

Revision: 1st July 2021

toc | top

Abstract

The IMS OneRoster (OR) standard addresses the exchange of student data (primarily about people, courses, enrollments and grades) between different educational systems for the specific needs of K-12. The primary use-case is the exchange of data between a Student Information System (SIS) and Learning Management System (LMS). In OR 1.2, the service has been split into three core services:

This OR 1.2 Resources Service provides the ability to manage the allocation of resources to classes, courses and users. It does NOT enable access to the resources themselves. A OneRoster resource is a description of a resource with sufficient information such that the resource itself could be obtained. In this document the data exchange is described in an implementation-independent format i.e. using a profile of the Unified Modeling Language (UML). The service description includes the definition of the data formats that are exchanged using a set of service operations.

toc | top

Table of Contents

Abstract

1. Introduction

1.1 Scope and Context

1.2 Conventions

1.3 Changes in the Resources Service 1.2

1.4 Structure of this Document

1.5 Nomenclature

2. Use-cases

3. Service Architecture and Specification Model

3.1 An Abstract Representation

3.2 Service Providers and Service Consumers

3.3 Service Objects

3.4 Synchronous and Asynchronous Services

3.5 OneRoster Rostering and Resources Choreography

4. The Behavior Model

4.1 Service Definition

4.2 "ClassesManagement" Interface Description

4.2.1 "getResourcesForClass" Operation

4.3 "CoursesManagement" Interface Description

4.3.1 "getResourcesForCourse" Operation

4.4 "ResourcesManagement" Interface Description

4.4.1 "getAllResources" Operation

4.4.2 "getResource" Operation

4.5 "UsersManagement" Interface Description

4.5.1 "getResourcesForUser" Operation

5. The Interface Data Model

5.1 "GUID" Class Description

5.2 "ResourceSet" Class Description

5.2.1 "resources" Attribute Description

5.3 "SingleResource" Class Description

5.3.1 "resource" Attribute Description

5.4 "imsx_StatusInfo" Class Description

5.4.1 "imsx_codeMajor" Attribute Description

5.4.2 "imsx_severity" Attribute Description

5.4.3 "imsx_description" Attribute Description

5.4.4 "imsx_CodeMinor" Attribute Description

6. The Data Model

6.1 Data Class Descriptions

6.1.1 "Base" Class Description

6.1.1.1 "sourcedId" Attribute Description

6.1.1.2 "status" Attribute Description

6.1.1.3 "dateLastModified" Attribute Description

6.1.1.4 "metadata" Attribute Description

6.1.2 "Metadata" Class Description

6.1.2.1 "extensions" Attribute Description

6.1.3 "Resource" Class Description

6.1.3.1 "title" Attribute Description

6.1.3.2 "roles" Attribute Description

6.1.3.3 "importance" Attribute Description

6.1.3.4 "vendorResourceId" Attribute Description

6.1.3.5 "vendorId" Attribute Description

6.1.3.6 "applicationId" Attribute Description

6.1.4 "ResourceSet" Class Description

6.1.4.1 "resources" Attribute Description

6.1.5 "SingleResource" Class Description

6.1.5.1 "resource" Attribute Description

6.1.6 "imsx_CodeMinor" Class Description

6.1.6.1 "imsx_codeMinorField" Attribute Description

6.1.7 "imsx_CodeMinorField" Class Description

6.1.7.1 "imsx_codeMinorFieldName" Attribute Description

6.1.7.2 "imsx_codeMinorFieldValue" Attribute Description

6.1.8 "imsx_StatusInfo" Class Description

6.1.8.1 "imsx_codeMajor" Attribute Description

6.1.8.2 "imsx_severity" Attribute Description

6.1.8.3 "imsx_description" Attribute Description

6.1.8.4 "imsx_CodeMinor" Attribute Description

6.2 Derived Class Descriptions

6.2.1 "GUID" Class Description

6.2.2 "Identifier" Class Description

6.2.3 "RoleExtString" Class Description

6.2.3.1 "pattern" Attribute Description

6.3 Union Class Descriptions

6.3.1 "RoleEnumExt" Class Description

6.4 Enumerated Vocabulary Descriptions

6.4.1 "BaseStatusEnum" Vocabulary Description

6.4.2 "ImportanceEnum" Vocabulary Description

6.4.3 "RoleEnum" Vocabulary Description

6.4.4 "imsx_CodeMajorEnum" Vocabulary Description

6.4.5 "imsx_CodeMinorValueEnum" Vocabulary Description

6.4.6 "imsx_SeverityEnum" Vocabulary Description

7. Link Data Definitions

7.1 CPResource Link Data Description

8. Extending and Profiling the Service

8.1 Extending the Specification

8.1.1 Proprietary Operations

8.1.2 Proprietary Data Elements

8.1.3 Proprietary Vocabulary Terms

8.2 Profiling the Specification

References

Appendix A Modelling Concepts and Terms

A1 Behavior Descriptions Explanations

A1.1 Service Diagrams

A1.2 Operation Descriptions

A2 Interface Descriptions Explanations

A2.1 Parameter Model Diagrams

A2.2 Class Descriptions

A2.3 Attribute Descriptions

A3 Data Model Descriptions Explanations

A3.1 Data Model Diagrams

A3.2 Class Descriptions

A3.3 Attribute and Characteristic Descriptions

A3.4 Enumerated Vocabulary Descriptions

A3.5 External Vocabulary Descriptions

A3.6 Import Class Descriptions

A3.7 Link Data Descriptions

A3.8 Common Data Model Persistent Identifier Descriptions

Appendix B Service Status Codes

B1 Definition of the Status Codes

B1.1 Definition of the "CodeMajor" Values

B1.2 Definition of the "Severity" Values

B1.3 Definition of the "CodeMinor" Values

About this Document

List of Contributors

Revision History

toc | top

List of Figures

Figure 4.1 Service interface definitions

Figure 5.1 GUID class definitions

Figure 5.2 ResourceSet class definitions

Figure 5.3 SingleResource class definitions

Figure 5.4 imsx_StatusInfo class definitions

Figure 6.1.1 Base class definitions

Figure 6.1.2 Metadata class definitions

Figure 6.1.3 Resource class definitions

Figure 6.1.4 ResourceSet class definitions

Figure 6.1.5 SingleResource class definitions

Figure 6.1.6 imsx_CodeMinor class definitions

Figure 6.1.7 imsx_CodeMinorField class definitions

Figure 6.1.8 imsx_StatusInfo class definitions

Figure 6.2.1 GUID class definitions

Figure 6.2.2 Identifier class definitions

Figure 6.2.3 RoleExtString class definitions

Figure 6.3.1 RoleEnumExt class definitions

Figure 6.4.1 BaseStatusEnum class definitions

Figure 6.4.2 ImportanceEnum class definitions

Figure 6.4.3 RoleEnum class definitions

Figure 6.4.4 imsx_CodeMajorEnum class definitions

Figure 6.4.5 imsx_CodeMinorValueEnum class definitions

Figure 6.4.6 imsx_SeverityEnum class definitions

Figure 7.1 CPResource link data definition.

toc | top

List of Tables

Table 4.1 The set of interfaces.

Table 4.2 The set of operations for the "ClassesManagement" interface.

Table 4.3 The set of operations for the "CoursesManagement" interface.

Table 4.4 The set of operations for the "ResourcesManagement" interface.

Table 4.5 The set of operations for the "UsersManagement" interface.

Table 5.1 "GUID" Class Description

Table 5.2 "ResourceSet" Class Description

Table 5.2.1 "resources" Attribute Description

Table 5.3 "SingleResource" Class Description

Table 5.3.1 "resource" Attribute Description

Table 5.4 "imsx_StatusInfo" Class Description

Table 5.4.1 "imsx_codeMajor" Attribute Description

Table 5.4.2 "imsx_severity" Attribute Description

Table 5.4.3 "imsx_description" Attribute Description

Table 5.4.4 "imsx_CodeMinor" Attribute Description

Table 6.1.1 Base class definitions

Table 6.1.1.1 Description of the "sourcedId" attribute for the "Base" class

Table 6.1.1.2 Description of the "status" attribute for the "Base" class

Table 6.1.1.3 Description of the "dateLastModified" attribute for the "Base" class

Table 6.1.1.4 Description of the "metadata" attribute for the "Base" class

Table 6.1.2 Metadata class definitions

Table 6.1.2.1 Description of the "extensions" attribute for the "Metadata" class

Table 6.1.3 Resource class definitions

Table 6.1.3.1 Description of the "title" attribute for the "Resource" class

Table 6.1.3.2 Description of the "roles" attribute for the "Resource" class

Table 6.1.3.3 Description of the "importance" attribute for the "Resource" class

Table 6.1.3.4 Description of the "vendorResourceId" attribute for the "Resource" class

Table 6.1.3.5 Description of the "vendorId" attribute for the "Resource" class

Table 6.1.3.6 Description of the "applicationId" attribute for the "Resource" class

Table 6.1.4 ResourceSet class definitions

Table 6.1.4.1 Description of the "resources" attribute for the "ResourceSet" class

Table 6.1.5 SingleResource class definitions

Table 6.1.5.1 Description of the "resource" attribute for the "SingleResource" class

Table 6.1.6 imsx_CodeMinor class definitions

Table 6.1.6.1 Description of the "imsx_codeMinorField" attribute for the "imsx_CodeMinor" class

Table 6.1.7 imsx_CodeMinorField class definitions

Table 6.1.7.1 Description of the "imsx_codeMinorFieldName" attribute for the "imsx_CodeMinorField" class

Table 6.1.7.2 Description of the "imsx_codeMinorFieldValue" attribute for the "imsx_CodeMinorField" class

Table 6.1.8 imsx_StatusInfo class definitions

Table 6.1.8.1 Description of the "imsx_codeMajor" attribute for the "imsx_StatusInfo" class

Table 6.1.8.2 Description of the "imsx_severity" attribute for the "imsx_StatusInfo" class

Table 6.1.8.3 Description of the "imsx_description" attribute for the "imsx_StatusInfo" class

Table 6.1.8.4 Description of the "imsx_CodeMinor" attribute for the "imsx_StatusInfo" class

Table 6.2.1 GUID class definitions

Table 6.2.2 Identifier class definitions

Table 6.2.3 RoleExtString class definitions

Table 6.2.3.1 Description of the "pattern" attribute for the "RoleExtString" class

Table 6.3.1 RoleEnumExt class description

Table 6.4.1 BaseStatusEnum class definitions

Table 6.4.2 ImportanceEnum class definitions

Table 6.4.3 RoleEnum class definitions

Table 6.4.4 imsx_CodeMajorEnum class definitions

Table 6.4.5 imsx_CodeMinorValueEnum class definitions

Table 6.4.6 imsx_SeverityEnum class definitions

Table 7.1 Description of the CPResource link data class.

Table A3.1 The key to the descriptions of data model diagrams

Table A3.2 The key to the descriptions of the data class tables

Table A3.3 The key to the descriptions of the data attribute/characteristic tables

Table A3.4 The key to the descriptions of the enumerated vocabulary tables

Table A3.5 The key to the descriptions of the external vocabulary tables

Table A3.6 The key to the descriptions of the import class tables

Table A3.7 The key to the descriptions of the link data tables

Table A3.8 The key to the descriptions of the common data model persistent identifier tables

toc | top

1. Introduction

This Section is NOT NORMATIVE.

1.1. Scope and Context

This document is the OneRoster 1.2 Resources Service Model and as such it is used as the basis for the development of the following documents:

This information model defines the OneRoster Resources Abstract Application Programming Interface (a-API). This service model is described using the Unified Modeling Language (UML) based upon the IMS Global Model Driven Specification approach and the associated modelling toolkit [I-BAT, 06]. This means that this specification is based upon the concepts of:

1.2. Conventions

All sections marked as non-normative, all authoring guidelines, diagrams (with the exception of the UML diagrams), examples, and notes in this specification are non-normative. Everything else in this specification is normative.

The key words "MUST", "MUST NOT", "REQUIRED", "SHALL", "SHALL NOT", "SHOULD", "SHOULD NOT", "RECOMMENDED", "MAY", and "OPTIONAL" in this document are to be interpreted as described in [RFC 2119]. This means that from the perspective of conformance:

The Conformance and Certification Guide for this specification may introduce greater normative constraints than those defined here for specific service or implementation categories.

The SHOULD/SHOULD NOT/RECOMMENDED statements MUST NOT be used in any document, or section of a document, that is responsible for defining the information model and/or the associated bindings and/or conformance and certification.

1.3. Changes in the Resources Service 1.2

The only changes made in this new version are:

1.4. Structure of this Document

The structure of the rest of this document is:

2. Use-cases The set resource allocation use-cases that are a supported by this service. Only a one-line summary of each use-case is provided;
3. Service Architecture and Specification Model An overview of the service including the key use-cases and the underlying service architecture and end-system service objects;
4. The Behavior Model The definition of the operations of the service. This focuses on the description of the behaviors supported by the service. The behaviors are grouped as interfaces;
5. The Interface Data Model The definition of the data models exchanged between the service End Systems. These are the parameters exchanged across the interoperability interface. These are an abbreviated description with the full set of details in the corresponding data class description;
6. The Data Model The definition of the data classes for the full data exchange. This addresses the data classes used to supplement the interface parameters. The descriptions are grouped according to their type e.g. data, enumeration, derived, etc.
7. Link Data Definitions The set of descriptions for the link data definitions that are used to establish the intra- and inter- specification relationships;
8. Extending and Profiling the Service An explanation of how the service can be extended, using the permitted points of extension and/or profiled. Profiling is the process by which the specification is tailored to a specific set of market/domain requirements;
References The set of cited documents, normative and informative, that are used to support the technical details in this document;
Appendix A Modelling Concepts and Terms An overview of the model driven approach, the concepts and the terms used by IMS to create the service model representations (based upon a profile of UML), the corresponding set of bindings and the accompanying documentation (including this information model);
Appendix B Service Status Codes A summary list of the status codes, and their causes, that can be returned by each of the operations forming the service. These describe the end-to-end status of the transaction.

1.5. Nomenclature

API Application Programming Interface
GUID Globally Unique Identifier
HTTP Hypertext Transfer Protocol
I-BAT IMS Binding Autogeneration Toolkit
IETF Internet Engineering Task Force
JSON Java Script Object Notation
LIS Learning Information Services
NCES National Centre for Education Statistics
OAS OpenAPI Specification
PII Personally Identifiable Information
REST Representational State Transfer
RFC Request for Comments
TLS Transport Layer Security
UML Unified Modeling Language
URI Uniform Resource Identifier
URL Uniform Resource Locator
UTC Coordinated Universal Time
YAML Yet Another Markup Language

toc | top

2. Use-cases

This Section is NOT NORMATIVE.

The set of use-cases addressed by the OR Resources Service are summarised in Table 2.1.

Table 2.1 - The list of use-cases enabled by this OneRoster service.
ID Use-case Description
1 To enable a system to obtain information about the set of resources that should be used when taking a specific class.
To provide the set of identifiers that are allocated to a class.
2 To enable a system to obtain information about the set of resources that should be used when taking a specific course.
To provide the set of identifiers that are allocated to a course.
3 To enable a system to obtain information about the set of resources that should be made available to a specific user.
To provide the set of identifiers that are allocated to a user.

toc | top

3. Service Architecture and Specification Model

This Section is NOT NORMATIVE.

3.1. An Abstract Representation

It is important to remember that this document contains a description of the underlying service model in terms of the abstract Application Programming Interface (API). The manner in which this abstract representation is visualized is not intended to dictate the implementation form of the Service. The breakdown of the service into its interface classes is a convenient way to document the set of behaviors. The objective for producing these interfaces is to identify and define the messages that are exchanged between the end-systems to realize the system behaviors required of the service.

The internal organization of an implementation of the full abstract API is beyond the scope of this specification. The only constraint is that the external behavior of the abstract API complies with this specification. This means that a .NET, J2EE, etc. physical implementation of this abstract API does not have to represent the functionality using the same breakdown of operations/methods. This physical implementation is not subject to the conformance specification.

It is important to note that the UML representation of the interfaces is used to help develop and document the Service Model and various Bindings. It is not a requirement for a system to implement this interface as defined i.e. to use the same parameters, etc. Conformance against this specification will be confirmed by inspecting the appropriate binding of the information model and ensuring that the relevant information is present and that different sequences of activity result in the predicted and mandated behavior. It is essential that the behaviors described by each of the operations are fully supported and that the behaviors described by different sequences are also maintained.

3.2. Service Providers and Service Consumers

The basic architectural model for the OR Resources Service specification is shown in Figure 3.1. In this architecture the scope of the IMS OR Resources Service specification is shown as the dotted line. The scope of the interoperability is the data and behavioral models of the objects being exchanged.

Diagram of the OR Resources service architecture.

Figure 3.1 - The OR Resources service architecture.

It is important to remember that the structure of the exchanged information has NO bearing on how the same information is contained within the 'consumer' and 'provider' OR Resources systems (the OR Resources repositories in the two end-systems). It is simply a representation of the data used to facilitate exchange between the end-systems. The only constraint on the end-system repositories is that they provide data persistence consistent with the required behavior.

3.3. Service Objects

The set of service objects that are exchanged between end-systems are:

The set of service collection objects that are exchanged between end-systems are:

A class and/or a course and/or a user has a set of associated resources. A class, course and user MUST reference the set of associated resources. A UML class representation of this set of relationships is shown in Figure 3.2.

Diagram of the logical relationships between Resources and Classes, Courses and Users.

Figure 3.2 - The logical relationships between resources and classes, courses and users.

In general a resource will be associated with more than one class and/or course and/or user.

3.4. Synchronous and Asynchronous Services

The OR Resources Service is a synchronous service i.e. the consumer is blocked until the response from the provider is received. This means that a consumer can only have one outstanding request with a service provider. The corresponding sequence of actions is shown in Figure 3.3.

Diagram of the action sequence for the OR Resources synchronous service.

Figure 3.3 - The action sequence for the OR Resources synchronous service.

Figure 3.3 shows the action sequence from the prespective of the consumer but it must be noted that a Service Provider will be expected to support concurrent requests from many consumers.

3.5. OneRoster Rostering and Resources Choreography

Apart from the 'getAllResources()' call, the other calls require provision of a 'sourcedId' to identify either the resource itself or the associated class or course. Therefore, support for the Resources endpoints should also require support for the OR Rostering endpoints. The Class and Course classes contain the set of sourcedIds for the resources associated with the class or course retrospectively and so this is the entry point for obtaining the associated resource allocations.

toc | top

4. The Behavior Model

This Section is NORMATIVE

4.1 Service Definition

The model for the service representation is shown in Figure 4.1 and Table 4.1 (the syntax and semantics for this representation is described in Appendix A1.1). Following the service definition are the descriptions for the set of corresponding service operations (the syntax and semantics for these descriptions is described in Appendix A1.2).

UML model of the service.

Figure 4.1 - Service interface definitions.

Table 4.1 The set of interfaces.
Interface Description
ClassesManagement This enables the management of information about resources i.e. the allocation of resources to classes.
CoursesManagement This enables the management of information about resources i.e. the allocation of resources to courses.
ResourcesManagement This enables the management of information about resources.
UsersManagement This enables the management of information about resources i.e. the allocation of resources to courses.

4.2 ClassesManagement Interface Description

This enables the management of information about resources i.e. the allocation of resources to classes.

The set of operations for this interface are summarized in Table 4.2.

Table 4.2 The set of operations for the "ClassesManagement" interface.
Operation Description
getResourcesForClass To read, get, the collection of resources associated to the specified class. This is the OneRoster description of the resources and not the actual resources. If the specified class cannot be identified within the service provider then a status code of 'unknownobject' must be reported.

4.2.1 "getResourcesForClass" Operation

Name: getResourcesForClass ()
Return Function Parameter: statusInfo : imsx_StatusInfo - the status information report for the request. This report has end-to-end significance and must map between the messaging technology approach and the business transaction API. For REST-based bindings this structure describes the message payload that must be returned when the request has not been successfully completed.
Supplied (in) Parameters: classSourcedId : GUID - the unique identifier, GUID, for this class.
Returned (out) Parameters: resources : ResourceSet - the set of OneRoster resource descriptions that are used by the specified class.
Behavior: To read, get, the collection of resources associated to the specified class. This is the OneRoster description of the resources and not the actual resources. If the specified class cannot be identified within the service provider then a status code of 'unknownobject' must be reported.

4.3 CoursesManagement Interface Description

This enables the management of information about resources i.e. the allocation of resources to courses.

The set of operations for this interface are summarized in Table 4.3.

Table 4.3 The set of operations for the "CoursesManagement" interface.
Operation Description
getResourcesForCourse To read, get, the collection of resources associated to the specified course. This is the OneRoster description of the resources and not the actual resources. If the specified class cannot be identified within the service provider then a status code of 'unknownobject' must be reported.

4.3.1 "getResourcesForCourse" Operation

Name: getResourcesForCourse ()
Return Function Parameter: statusInfo : imsx_StatusInfo - the status information report for the request. This report has end-to-end significance and must map between the messaging technology approach and the business transaction API. For REST-based bindings this structure describes the message payload that must be returned when the request has not been successfully completed.
Supplied (in) Parameters: courseSourcedId : GUID - the unique identifier, GUID, for the course.
Returned (out) Parameters: resources : ResourceSet - the set of OneRoster resource descriptions that are used by the specified course.
Behavior: To read, get, the collection of resources associated to the specified course. This is the OneRoster description of the resources and not the actual resources. If the specified class cannot be identified within the service provider then a status code of 'unknownobject' must be reported.

4.4 ResourcesManagement Interface Description

This enables the management of information about resources.

The set of operations for this interface are summarized in Table 4.4.

Table 4.4 The set of operations for the "ResourcesManagement" interface.
Operation Description
getAllResources To read, get, a collection of resources i.e. all resources. This is the OneRoster description of the resources and not the actual resources.
getResource To read, get, a specific OneRoster resource description. If the specified class cannot be identified within the service provider then a status code of 'unknownobject' must be reported.

4.4.1 "getAllResources" Operation

Name: getAllResources ()
Return Function Parameter: statusInfo : imsx_StatusInfo - the status information report for the request. This report has end-to-end significance and must map between the messaging technology approach and the business transaction API. For REST-based bindings this structure describes the message payload that must be returned when the request has not been successfully completed.
Supplied (in) Parameters: None.
Returned (out) Parameters: resources : ResourceSet - the set of OneRoster resource descriptions that have been read from the service provider.
Behavior: To read, get, a collection of resources i.e. all resources. This is the OneRoster description of the resources and not the actual resources.

4.4.2 "getResource" Operation

Name: getResource ()
Return Function Parameter: statusInfo : imsx_StatusInfo - the status information report for the request. This report has end-to-end significance and must map between the messaging technology approach and the business transaction API. For REST-based bindings this structure describes the message payload that must be returned when the request has not been successfully completed.
Supplied (in) Parameters: sourcedId : GUID - the unique identifier, GUID, for the resource.
Returned (out) Parameters: resource : SingleResource - the OneRoster resource description that has been read from the service provider.
Behavior: To read, get, a specific OneRoster resource description. If the specified class cannot be identified within the service provider then a status code of 'unknownobject' must be reported.

4.5 UsersManagement Interface Description

This enables the management of information about resources i.e. the allocation of resources to courses.

The set of operations for this interface are summarized in Table 4.5.

Table 4.5 The set of operations for the "UsersManagement" interface.
Operation Description
getResourcesForUser To read, get, the collection of resources available to the specified user. This is the OneRoster description of the resources and not the actual resources. If the specified user cannot be identified within the service provider then a status code of 'unknownobject' must be reported.

4.5.1 "getResourcesForUser" Operation

Name: getResourcesForUser ()
Return Function Parameter: imsx_StatusInfo : imsx_StatusInfo - the status information report for the request. This report has end-to-end significance and must map between the messaging technology approach and the business transaction API. For REST-based bindings this structure describes the message payload that must be returned when the request has not been successfully completed.
Supplied (in) Parameters: userSourcedId : GUID - the unique identifier, GUID, for the user.
Returned (out) Parameters: resources : ResourceSet - the set of OneRoster resource descriptions that are available to the specified user.
Behavior: To read, get, the collection of resources available to the specified user. This is the OneRoster description of the resources and not the actual resources. If the specified user cannot be identified within the service provider then a status code of 'unknownobject' must be reported.

toc | top

5. The Interface Data Model

This Section is NORMATIVE

The set of operations described within the behavior model (The Behavior Model) are based upon class descriptions specific to the parameters of the operations. All parameters are mandatory. The syntax and semantics for this representation is described in Appendix A2.

5.1 GUID Class Description

The data model for the "GUID" class is shown in Figure 5.1 and the accompanying definition in Table 5.1.

UML diagram of the GUID class.

Figure 5.1 - GUID class definitions.

Table 5.1 Description of the "GUID" class.
Descriptor Definition
Class Name GUID
Class Type Container [ DerivedType ]
Parents Service parameter data-type used in the following operations:
Characteristics There are no characteristics.
Children There are no children.
Description The data-type for establishing a Globally Unique Identifier (GUID). This is the data-type used for a 'sourcedId'. There is no predefined structure for the GUID.

5.2 ResourceSet Class Description

The data model for the "ResourceSet" class is shown in Figure 5.2 and the accompanying definition in Table 5.2.

UML diagram of the ResourceSet class.

Figure 5.2 - ResourceSet class definitions.

Table 5.2 Description of the "ResourceSet" class.
Descriptor Definition
Class Name ResourceSet
Class Type Container [ Sequence ]
Parents Service parameter data-type used in the following operations:
Characteristics There are no characteristics.
Children The set of children attributes are:
Description The container for a collection of resource records. The order is not significant. This may be empty. The service provider may not have any resources or cannot identfiy any resources that fit the specified filter constraints.

5.2.1 "resources" Attribute Description

The description of the "resources" attribute for the "ResourceSet" class is given in Table 5.2.1.

Table 5.2.1 Description of the "resources" attribute for the "ResourceSet" class.
Descriptor Definition
Attribute Name resources
Data Type Resource
Value Space Container [ Sequence ]
Scope Local ("-")
Multiplicity [0.. unbounded]
Description The set of contained resource identfiers.

5.3 SingleResource Class Description

The data model for the "SingleResource" class is shown in Figure 5.3 and the accompanying definition in Table 5.3.

UML diagram of the SingleResource class.

Figure 5.3 - SingleResource class definitions.

Table 5.3 Description of the "SingleResource" class.
Descriptor Definition
Class Name SingleResource
Class Type Container [ Sequence ]
Parents Service parameter data-type used in the following operations:
Characteristics There are no characteristics.
Children The set of children attributes are:
Description The container for a single resource. This may be empty i.e. the resource has no properties that obey any of the specified selection criteria.

5.3.1 "resource" Attribute Description

The description of the "resource" attribute for the "SingleResource" class is given in Table 5.3.1.

Table 5.3.1 Description of the "resource" attribute for the "SingleResource" class.
Descriptor Definition
Attribute Name resource
Data Type Resource
Value Space Container [ Sequence ]
Scope Local ("-")
Multiplicity [1]
Description The label for the contained resource.

5.4 imsx_StatusInfo Class Description

The data model for the "imsx_StatusInfo" class is shown in Figure 5.4 and the accompanying definition in Table 5.4.

UML diagram of the imsx_StatusInfo class.

Figure 5.4 - imsx_StatusInfo class definitions.

Table 5.4 Description of the "imsx_StatusInfo" class.
Descriptor Definition
Class Name imsx_StatusInfo
Class Type Container [ Sequence ]
Parents Service parameter data-type used in the following operations:
Characteristics There are no characteristics.
Children The set of children attributes are:
Description This is the container for the status code and associated information returned within the HTTP messages received from the Service Provider. For the OneRoster Resources service this object will only be returned to provide information about a failed request i.e. it will NOT be in the payload for a successful request. See Appendix B for further information on the interpretation of the information contained within this class.

5.4.1 "imsx_codeMajor" Attribute Description

The description of the "imsx_codeMajor" attribute for the "imsx_StatusInfo" class is given in Table 5.4.1.

Table 5.4.1 Description of the "imsx_codeMajor" attribute for the "imsx_StatusInfo" class.
Descriptor Definition
Attribute Name imsx_codeMajor
Data Type imsx_CodeMajorEnum
Value Space Enumerated value set of: { success | processing | failure | unsupported }
Scope Local ("-")
Multiplicity [1]
Description The code major value (from the corresponding enumerated vocabulary). See Appendix B for further information on the interpretation of this set of codes. The permitted vocabulary for the values for the CodeMajor field.

5.4.2 "imsx_severity" Attribute Description

The description of the "imsx_severity" attribute for the "imsx_StatusInfo" class is given in Table 5.4.2.

Table 5.4.2 Description of the "imsx_severity" attribute for the "imsx_StatusInfo" class.
Descriptor Definition
Attribute Name imsx_severity
Data Type imsx_SeverityEnum
Value Space Enumerated value set of: { status | warning | error }
Scope Local ("-")
Multiplicity [1]
Description The severity value (from the corresponding enumerated vocabulary). See Appendix B for further information on the interpretation of this set of codes.

5.4.3 "imsx_description" Attribute Description

The description of the "imsx_description" attribute for the "imsx_StatusInfo" class is given in Table 5.4.3.

Table 5.4.3 Description of the "imsx_description" attribute for the "imsx_StatusInfo" class.
Descriptor Definition
Attribute Name imsx_description
Data Type String (Primitive-type)
Value Space See Appendix A3.3.
Scope Local ("-")
Multiplicity [0..1]
Description A human readable description supplied by the entity creating the status code information.

5.4.4 "imsx_CodeMinor" Attribute Description

The description of the "imsx_CodeMinor" attribute for the "imsx_StatusInfo" class is given in Table 5.4.4.

Table 5.4.4 Description of the "imsx_CodeMinor" attribute for the "imsx_StatusInfo" class.
Descriptor Definition
Attribute Name imsx_CodeMinor
Data Type imsx_CodeMinor
Value Space Container [ Sequence ]
Scope Local ("-")
Multiplicity [0..1]
Description The set of reported code minor status codes. See Appendix B for further information on the interpretation of this set of codes.

toc | top

6. The Data Model

6.1. Data Class Descriptions

This Section is NORMATIVE.

All of the data classes used within this Information Model are described in this Section. The syntax and semantics for this representation is described in Appendix A3.2.

6.1.1 Base Class Description

The data model for the "Base" class is shown in Figure 6.1.1 and the accompanying definition in Table 6.1.1.

UML diagram of the Base class.

Figure 6.1.1 - Base class definitions.

Table 6.1.1 Description of the "Base" class.
Descriptor Definition
Class Name Base
Class Type Container [ Sequence ]
Parents There are no parent classes.
Derived Classes The set of derived classes are:
Super Classes This class is not derived from another class.
Characteristics There are no characteristics.
Children The set of children attributes are:
Description This is the base class which all of the first class objects in the Resource service inherit. It defines the instance's unique, interoperability identifier, the status of the instance data and the date the data was last changed. It all defines how the data model can be extended using the 'metadata' structure.

6.1.1.1 "sourcedId" Attribute Description

The description of the "sourcedId" attribute for the "Base" class is given in Table 6.1.1.1.

Table 6.1.1.1 Description of the "sourcedId" attribute for the "Base" class.
Descriptor Definition
Attribute Name sourcedId
Data Type GUID
Value Space Container [ DerivedType ]
Scope Local ("-")
Multiplicity [1]
Description All Objects MUST be identified by a Source Identifier. This is a GUID i.e. a unique system interoperability identifier for an object. This is the GUID that SYSTEMS will refer to when making API calls, or when needing to identify an object. It is RECOMMENDED that systems are able to map whichever local identifiers (e.g. database key fields) they use to the corresponding SourcedId. The sourcedId of an object is considered an addressable property of an entity and as such will not be treated as Personally Identifiable Information (PII) by certified products. Therefore, as a part of certification, vendors will be required to declare that they will notify customers via documentation or other formal and documented agreement that sourcedIds should never contain PII in general, but particularly users. This means that if a customer includes a student name in an enrollment.sourcedId, it will not fall to any certified product to protect the enrollment.sourcedId as PII, or even the userSourcedId field in the enrollment record.

6.1.1.2 "status" Attribute Description

The description of the "status" attribute for the "Base" class is given in Table 6.1.1.2.

Table 6.1.1.2 Description of the "status" attribute for the "Base" class.
Descriptor Definition
Attribute Name status
Data Type BaseStatusEnum
Value Space Enumerated value set of: { active | tobedeleted }
Scope Local ("-")
Multiplicity [1]
Description All objects MUST BE either 'active' or 'tobedeleted'. Something which is flagged 'tobedeleted' is to be considered safe to delete. Systems can delete records that are flagged as such if they wish, but they are not under any compulsion to do so. NOTE: In v1.1 the enumeration value of 'inactive' was removed and so for backwards compatibility all such marked objects should be interpreted as 'tobedeleted'.

6.1.1.3 "dateLastModified" Attribute Description

The description of the "dateLastModified" attribute for the "Base" class is given in Table 6.1.1.3.

Table 6.1.1.3 Description of the "dateLastModified" attribute for the "Base" class.
Descriptor Definition
Attribute Name dateLastModified
Data Type DateTime (Primitive-type)
Value Space See Appendix A3.3.
Scope Local ("-")
Multiplicity [1]
Description All objects MUST be annotated with the dateTime upon which they were last modified. This enables requesters to query for just the latest objects. DateTimes MUST be expressed in W3C profile of [ISO 8601] and MUST contain the UTC timezone.

6.1.1.4 "metadata" Attribute Description

The description of the "metadata" attribute for the "Base" class is given in Table 6.1.1.4.

Table 6.1.1.4 Description of the "metadata" attribute for the "Base" class.
Descriptor Definition
Attribute Name metadata
Data Type Metadata
Value Space Container [ Sequence ]
Scope Local ("-")
Multiplicity [0..1]
Description All objects CAN be extended using the Metadata class. This specification is silent on what implementers may consider to be appropriate extensions.

6.1.2 Metadata Class Description

The data model for the "Metadata" class is shown in Figure 6.1.2 and the accompanying definition in Table 6.1.2.

UML diagram of the Metadata class.

Figure 6.1.2 - Metadata class definitions.

Table 6.1.2 Description of the "Metadata" class.
Descriptor Definition
Class Name Metadata
Class Type Container [ Sequence ]
Parents The set of parent classes are:
Derived Classes There are no derived classes.
Super Classes This class is not derived from another class.
Characteristics There are no characteristics.
Children The set of children attributes are:
Description This is the container for the data model extensions that may be assigned to the associated class of objects.

6.1.2.1 "extensions" Attribute Description

The description of the "extensions" attribute for the "Metadata" class is given in Table 6.1.2.1.

Table 6.1.2.1 Description of the "extensions" attribute for the "Metadata" class.
Descriptor Definition
Attribute Name extensions
Data Type Namespace (Primitive-type)
Value Space See Appendix A3.3.
Scope Global ("+")
Multiplicity [0.. unbounded]
Description The form of the extension will be determined by the associated binding (for examples see [OR-IMPL-12]).

6.1.3 Resource Class Description

The data model for the "Resource" class is shown in Figure 6.1.3 and the accompanying definition in Table 6.1.3.

UML diagram of the Resource class.

Figure 6.1.3 - Resource class definitions.

Table 6.1.3 Description of the "Resource" class.
Descriptor Definition
Class Name Resource
Class Type Container [ Sequence ]
Parents The set of parent classes are:
Derived Classes There are no derived classes.
Super Classes The set of classes from which this class is derived:
Characteristics There are no characteristics.
Children The set of children attributes are: The set of directly inherited children attributes are:
Link Data The set of attributes that are used to provide links to other data objects are:
Description A resource is a description of learning content that is related to a course and/or a class and/or a user. This identifies a resource that is used by a teacher, learner, etc. as part of the learning experience. A resource MUST be associated to a course and/or a class.

6.1.3.1 "title" Attribute Description

The description of the "title" attribute for the "Resource" class is given in Table 6.1.3.1.

Table 6.1.3.1 Description of the "title" attribute for the "Resource" class.
Descriptor Definition
Attribute Name title
Data Type NormalizedString (Primitive-type)
Value Space See Appendix A3.3.
Scope Local ("-")
Multiplicity [0..1]
Description A human readable title/label for the resource.

6.1.3.2 "roles" Attribute Description

The description of the "roles" attribute for the "Resource" class is given in Table 6.1.3.2.

Table 6.1.3.2 Description of the "roles" attribute for the "Resource" class.
Descriptor Definition
Attribute Name roles
Data Type RoleEnumExt
Value Space Container [ Union ]
Scope Local ("-")
Multiplicity [0.. unbounded]
Description The set of roles, types of users, who are expected to make use of the resource.

6.1.3.3 "importance" Attribute Description

The description of the "importance" attribute for the "Resource" class is given in Table 6.1.3.3.

Table 6.1.3.3 Description of the "importance" attribute for the "Resource" class.
Descriptor Definition
Attribute Name importance
Data Type ImportanceEnum
Value Space Enumerated value set of: { primary | secondary }
Scope Local ("-")
Multiplicity [0..1]
Description This is an indicator of the significance of the resource i.e. primary or secondary.

6.1.3.4 "vendorResourceId" Attribute Description

The description of the "vendorResourceId" attribute for the "Resource" class is given in Table 6.1.3.4.

Table 6.1.3.4 Description of the "vendorResourceId" attribute for the "Resource" class.
Descriptor Definition
Attribute Name vendorResourceId
Data Type Identifier
Value Space Container [ DerivedType ]
Scope Local ("-")
Multiplicity [1]
Description This is a unique identifier for the resource allocated by the vendor.
Link Data In the context of the IMS Ecosystem this is a pointer to the actual resource as defined within a Content Package/Common Cartridge/Thin Common Cartridge. The value for the vendorResourceId MUST have the same value as the identifier for the actual resource in the Package/Cartridge. It is the responsibility of the learning/content management systems to be able to reconcile this identifer mapping.
See CPResource for the details about this link.

6.1.3.5 "vendorId" Attribute Description

The description of the "vendorId" attribute for the "Resource" class is given in Table 6.1.3.5.

Table 6.1.3.5 Description of the "vendorId" attribute for the "Resource" class.
Descriptor Definition
Attribute Name vendorId
Data Type Identifier
Value Space Container [ DerivedType ]
Scope Local ("-")
Multiplicity [0..1]
Description Identifier for the vendor who created the resource. This will be assigned by IMS Global as part of Conformance Certification.

6.1.3.6 "applicationId" Attribute Description

The description of the "applicationId" attribute for the "Resource" class is given in Table 6.1.3.6.

Table 6.1.3.6 Description of the "applicationId" attribute for the "Resource" class.
Descriptor Definition
Attribute Name applicationId
Data Type Identifier
Value Space Container [ DerivedType ]
Scope Local ("-")
Multiplicity [0..1]
Description Identifier for the application associated with the resource. The nature, and how this identifier is assigned is not defined by this specification.

6.1.4 ResourceSet Class Description

The data model for the "ResourceSet" class is shown in Figure 6.1.4 and the accompanying definition in Table 6.1.4.

UML diagram of the ResourceSet class.

Figure 6.1.4 - ResourceSet class definitions.

Table 6.1.4 Description of the "ResourceSet" class.
Descriptor Definition
Class Name ResourceSet
Class Type Container [ Sequence ]
Parents There are no parent classes.
Derived Classes There are no derived classes.
Super Classes This class is not derived from another class.
Characteristics There are no characteristics.
Children The set of children attributes are:
Description The container for a collection of resource records. The order is not significant. This may be empty. The service provider may not have any resources or cannot identfiy any resources that fit the specified filter constraints.

6.1.4.1 "resources" Attribute Description

The description of the "resources" attribute for the "ResourceSet" class is given in Table 6.1.4.1.

Table 6.1.4.1 Description of the "resources" attribute for the "ResourceSet" class.
Descriptor Definition
Attribute Name resources
Data Type Resource
Value Space Container [ Sequence ]
Scope Local ("-")
Multiplicity [0.. unbounded]
Description The set of contained resource identfiers.

6.1.5 SingleResource Class Description

The data model for the "SingleResource" class is shown in Figure 6.1.5 and the accompanying definition in Table 6.1.5.

UML diagram of the SingleResource class.

Figure 6.1.5 - SingleResource class definitions.

Table 6.1.5 Description of the "SingleResource" class.
Descriptor Definition
Class Name SingleResource
Class Type Container [ Sequence ]
Parents There are no parent classes.
Derived Classes There are no derived classes.
Super Classes This class is not derived from another class.
Characteristics There are no characteristics.
Children The set of children attributes are:
Description The container for a single resource. This may be empty i.e. the resource has no properties that obey any of the specified selection criteria.

6.1.5.1 "resource" Attribute Description

The description of the "resource" attribute for the "SingleResource" class is given in Table 6.1.5.1.

Table 6.1.5.1 Description of the "resource" attribute for the "SingleResource" class.
Descriptor Definition
Attribute Name resource
Data Type Resource
Value Space Container [ Sequence ]
Scope Local ("-")
Multiplicity [1]
Description The label for the contained resource.

6.1.6 imsx_CodeMinor Class Description

The data model for the "imsx_CodeMinor" class is shown in Figure 6.1.6 and the accompanying definition in Table 6.1.6.

UML diagram of the imsx_CodeMinor class.

Figure 6.1.6 - imsx_CodeMinor class definitions.

Table 6.1.6 Description of the "imsx_CodeMinor" class.
Descriptor Definition
Class Name imsx_CodeMinor
Class Type Container [ Sequence ]
Parents The set of parent classes are:
Derived Classes There are no derived classes.
Super Classes This class is not derived from another class.
Characteristics There are no characteristics.
Children The set of children attributes are:
Description This is the container for the set of code minor status codes reported in the responses from the Service Provider.

6.1.6.1 "imsx_codeMinorField" Attribute Description

The description of the "imsx_codeMinorField" attribute for the "imsx_CodeMinor" class is given in Table 6.1.6.1.

Table 6.1.6.1 Description of the "imsx_codeMinorField" attribute for the "imsx_CodeMinor" class.
Descriptor Definition
Attribute Name imsx_codeMinorField
Data Type imsx_CodeMinorField
Value Space Container [ Sequence ]
Scope Local ("-")
Multiplicity [1.. unbounded]
Description Each reported code minor status code.

6.1.7 imsx_CodeMinorField Class Description

The data model for the "imsx_CodeMinorField" class is shown in Figure 6.1.7 and the accompanying definition in Table 6.1.7.

UML diagram of the imsx_CodeMinorField class.

Figure 6.1.7 - imsx_CodeMinorField class definitions.

Table 6.1.7 Description of the "imsx_CodeMinorField" class.
Descriptor Definition
Class Name imsx_CodeMinorField
Class Type Container [ Sequence ]
Parents The set of parent classes are:
Derived Classes There are no derived classes.
Super Classes This class is not derived from another class.
Characteristics There are no characteristics.
Children The set of children attributes are:
Description This is the container for a single code minor status code.

6.1.7.1 "imsx_codeMinorFieldName" Attribute Description

The description of the "imsx_codeMinorFieldName" attribute for the "imsx_CodeMinorField" class is given in Table 6.1.7.1.

Table 6.1.7.1 Description of the "imsx_codeMinorFieldName" attribute for the "imsx_CodeMinorField" class.
Descriptor Definition
Attribute Name imsx_codeMinorFieldName
Data Type NormalizedString (Primitive-type)
Value Space See Appendix A3.3.
Default = "TargetEndSystem".
Scope Local ("-")
Multiplicity [1]
Description This should contain the identity of the system that has produced the code minor status code report. In most cases this will be the target service provider denoted as 'TargetEndSystem'.

6.1.7.2 "imsx_codeMinorFieldValue" Attribute Description

The description of the "imsx_codeMinorFieldValue" attribute for the "imsx_CodeMinorField" class is given in Table 6.1.7.2.

Table 6.1.7.2 Description of the "imsx_codeMinorFieldValue" attribute for the "imsx_CodeMinorField" class.
Descriptor Definition
Attribute Name imsx_codeMinorFieldValue
Data Type imsx_CodeMinorValueEnum
Value Space Enumerated value set of: { fullsuccess | invalid_filter_field | invalid_selection_field | forbidden | unauthorisedrequest | internal_server_error | server_busy | unknownobject | invaliddata }
Scope Local ("-")
Multiplicity [1]
Description The code minor status code (this is a value from the corresponding enumerated vocabulary).

6.1.8 imsx_StatusInfo Class Description

The data model for the "imsx_StatusInfo" class is shown in Figure 6.1.8 and the accompanying definition in Table 6.1.8.

UML diagram of the imsx_StatusInfo class.

Figure 6.1.8 - imsx_StatusInfo class definitions.

Table 6.1.8 Description of the "imsx_StatusInfo" class.
Descriptor Definition
Class Name imsx_StatusInfo
Class Type Container [ Sequence ]
Parents There are no parent classes.
Derived Classes There are no derived classes.
Super Classes This class is not derived from another class.
Characteristics There are no characteristics.
Children The set of children attributes are:
Description This is the container for the status code and associated information returned within the HTTP messages received from the Service Provider. For the OneRoster Resources service this object will only be returned to provide information about a failed request i.e. it will NOT be in the payload for a successful request. See Appendix B for further information on the interpretation of the information contained within this class.

6.1.8.1 "imsx_codeMajor" Attribute Description

The description of the "imsx_codeMajor" attribute for the "imsx_StatusInfo" class is given in Table 6.1.8.1.

Table 6.1.8.1 Description of the "imsx_codeMajor" attribute for the "imsx_StatusInfo" class.
Descriptor Definition
Attribute Name imsx_codeMajor
Data Type imsx_CodeMajorEnum
Value Space Enumerated value set of: { success | processing | failure | unsupported }
Scope Local ("-")
Multiplicity [1]
Description The code major value (from the corresponding enumerated vocabulary). See Appendix B for further information on the interpretation of this set of codes. The permitted vocabulary for the values for the CodeMajor field.

6.1.8.2 "imsx_severity" Attribute Description

The description of the "imsx_severity" attribute for the "imsx_StatusInfo" class is given in Table 6.1.8.2.

Table 6.1.8.2 Description of the "imsx_severity" attribute for the "imsx_StatusInfo" class.
Descriptor Definition
Attribute Name imsx_severity
Data Type imsx_SeverityEnum
Value Space Enumerated value set of: { status | warning | error }
Scope Local ("-")
Multiplicity [1]
Description The severity value (from the corresponding enumerated vocabulary). See Appendix B for further information on the interpretation of this set of codes.

6.1.8.3 "imsx_description" Attribute Description

The description of the "imsx_description" attribute for the "imsx_StatusInfo" class is given in Table 6.1.8.3.

Table 6.1.8.3 Description of the "imsx_description" attribute for the "imsx_StatusInfo" class.
Descriptor Definition
Attribute Name imsx_description
Data Type String (Primitive-type)
Value Space See Appendix A3.3.
Scope Local ("-")
Multiplicity [0..1]
Description A human readable description supplied by the entity creating the status code information.

6.1.8.4 "imsx_CodeMinor" Attribute Description

The description of the "imsx_CodeMinor" attribute for the "imsx_StatusInfo" class is given in Table 6.1.8.4.

Table 6.1.8.4 Description of the "imsx_CodeMinor" attribute for the "imsx_StatusInfo" class.
Descriptor Definition
Attribute Name imsx_CodeMinor
Data Type imsx_CodeMinor
Value Space Container [ Sequence ]
Scope Local ("-")
Multiplicity [0..1]
Description The set of reported code minor status codes. See Appendix B for further information on the interpretation of this set of codes.

6.2. Derived Class Descriptions

This Section is NORMATIVE.

All of the derived data classes used within this Information Model are described in this Section. The syntax and semantics for this representation is described in Appendix A3.2.

6.2.1 GUID Class Description

The data model for the "GUID" class is shown in Figure 6.2.1 and the accompanying definition in Table 6.2.1.

UML diagram of the GUID class.

Figure 6.2.1 - GUID class definitions.

Table 6.2.1 Description of the "GUID" class.
Descriptor Definition
Class Name GUID
Class Type Container [ DerivedType ]
Parents The set of parent classes are:
Derived Classes There are no derived classes.
Super Classes The set of classes from which this class is derived:
Characteristics There are no characteristics.
Children There are no children.
Description The data-type for establishing a Globally Unique Identifier (GUID). This is the data-type used for a 'sourcedId'. There is no predefined structure for the GUID.

6.2.2 Identifier Class Description

The data model for the "Identifier" class is shown in Figure 6.2.2 and the accompanying definition in Table 6.2.2.

UML diagram of the Identifier class.

Figure 6.2.2 - Identifier class definitions.

Table 6.2.2 Description of the "Identifier" class.
Descriptor Definition
Class Name Identifier
Class Type Container [ DerivedType ]
Parents The set of parent classes are:
Derived Classes There are no derived classes.
Super Classes The set of classes from which this class is derived:
Characteristics There are no characteristics.
Children There are no children.
Description The data-type for a unique identifier (but not a GUID). The format/structure of such an identifier is undefined.

6.2.3 RoleExtString Class Description

The data model for the "RoleExtString" class is shown in Figure 6.2.3 and the accompanying definition in Table 6.2.3.

UML diagram of the RoleExtString class.

Figure 6.2.3 - RoleExtString class definitions.

Table 6.2.3 Description of the "RoleExtString" class.
Descriptor Definition
Class Name RoleExtString
Class Type Container [ DerivedType ]
Parents There are no parent classes.
Derived Classes The set of derived classes are:
Super Classes The set of classes from which this class is derived:
Characteristics There are no characteristics.
Children The set of children attributes are:
Description The data-type that enables the 'RoleEnum' vocabulary to be extended.

6.2.3.1 "pattern" Attribute Description

The description of the "pattern" attribute for the "RoleExtString" class is given in Table 6.2.3.

Table 6.2.3 Description of the "pattern" attribute for the "RoleExtString" class.
Descriptor Definition
Attribute Name pattern
Data Type String (Primitive-type)
Value Space See Appendix A3.3.
Default = "(ext:)[a-zA-Z0-9\.\-_]+".
Scope Local ("-")
Multiplicity [1]
Description The regular expression to constrain the structure of the string that MUST be used when creating a new, proprietary, vocabulary term. The term must start with the substring 'ext:'.

6.3. Union Class Descriptions

The set of union classes used within this Information Model are described in this Section. The syntax and semantics for this representation is described in Appendix A3.2.

6.3.1 RoleEnumExt Class Description

The data model for the "RoleEnumExt" class is shown in Figure 6.3.1 and the accompanying definition in Table 6.3.1.

UML diagram of the RoleEnumExt class.

Figure 6.3.1 - RoleEnumExt class definitions.

Table 6.3.1 Description of the "RoleEnumExt" class.
Descriptor Definition
Class Name RoleEnumExt
Class Type Container [ Union ]
Parents The set of parent classes are:
Derived Classes There are no derived classes.
Super Classes The set of classes from which this class is derived:
Characteristics There are no characteristics.
Children The set of directly inherited children attributes are:
Description The data-type for the 'role' characteristic used to identify the type of user for whom the resources are targetted. This is an extensible enumerated vocabulary. Extending the vocabulary makes use of a naming convention.

6.4. Enumerated Vocabulary Descriptions

This Section is NORMATIVE.

All of the enumerated vocabularies used within this Information Model are described in this Section. The syntax and semantics for this representation is described in Appendix A3.4.

6.4.1 BaseStatusEnum Vocabulary Description

The permitted vocabulary for the status value of a record. The data model for the "BaseStatusEnum" enumerated class is shown in Figure 6.4.1 and the accompanying vocabulary definition in Table 6.4.1.

UML diagram of the BaseStatusEnum class.

Figure 6.4.1 - BaseStatusEnum class definitions.

Table 6.4.1 Description of the "BaseStatusEnum" enumerated vocabulary terms.
Term Definition
active An active record.
tobedeleted Denotes that it is safe to delete the record.

6.4.2 ImportanceEnum Vocabulary Description

The permitted vocabulary for the 'importance' value of a resource. The data model for the "ImportanceEnum" enumerated class is shown in Figure 6.4.2 and the accompanying vocabulary definition in Table 6.4.2.

UML diagram of the ImportanceEnum class.

Figure 6.4.2 - ImportanceEnum class definitions.

Table 6.4.2 Description of the "ImportanceEnum" enumerated vocabulary terms.
Term Definition
primary A resource of primary usage.
secondary A resource of secondary usage/significance.

6.4.3 RoleEnum Vocabulary Description

The permitted vocabulary for the 'role' value for the targeted user of a resource. The data model for the "RoleEnum" enumerated class is shown in Figure 6.4.3 and the accompanying vocabulary definition in Table 6.4.3.

UML diagram of the RoleEnum class.

Figure 6.4.3 - RoleEnum class definitions.

Table 6.4.3 Description of the "RoleEnum" enumerated vocabulary terms.
Term Definition
administrator Administrator in the organization (e.g. School).
aide Someone who provides appropriate aide to the user but NOT also one of the other roles.
guardian Guardian of the user and NOT the Mother or Father. May also be a Relative.
parent Mother or father of the user.
proctor Exam proctor. May be used for enrollment.
relative A relative of the user and NOT the Mother or Father. May also be the Guardian.
student A student at an organization (e.g. School).
teacher A Teacher at an organization (e.g. School).

6.4.4 imsx_CodeMajorEnum Vocabulary Description

The permitted vocabulary for the values for the CodeMajor field. The data model for the "imsx_CodeMajorEnum" enumerated class is shown in Figure 6.4.4 and the accompanying vocabulary definition in Table 6.4.4.

UML diagram of the imsx_CodeMajorEnum class.

Figure 6.4.4 - imsx_CodeMajorEnum class definitions.

Table 6.4.4 Description of the "imsx_CodeMajorEnum" enumerated vocabulary terms.
Term Definition
failure Denotes that the transaction request has failed. The detailed reason will be reported in the accompanying 'codeMinor' fields.
processing Denotes that the request is being processed at the destination or there has been a local transmission failure. This value is used in asynchronous services.
success Denotes that the request has been successfully completed. If the associated 'severity' value is 'warning' then the request has been partially successful i.e. best effort by the service provider. Other parts of the status information may provide more insight into a partial success response.
unsupported Denotes that the service provider does not support the requested operation. This is the required default response for an unsupported operation by an implementation.

6.4.5 imsx_CodeMinorValueEnum Vocabulary Description

The permitted vocabulary for the values for the CodeMinorValue field. The data model for the "imsx_CodeMinorValueEnum" enumerated class is shown in Figure 6.4.5 and the accompanying vocabulary definition in Table 6.4.5.

UML diagram of the imsx_CodeMinorValueEnum class.

Figure 6.4.5 - imsx_CodeMinorValueEnum class definitions.

Table 6.4.5 Description of the "imsx_CodeMinorValueEnum" enumerated vocabulary terms.
Term Definition
forbidden This is used to indicate that the server can be reached and process the request but refuses to take any further action. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and for a REST binding a HTTP code of '403'.
fullsuccess The request has been fully and successfully implemented by the Service Provider. For a REST binding this will have an HTTP code of '200' for a successful 'GET' request; '201' for a successful 'PUT' request; '204' for a successful 'DELETE' request.
internal_server_error This should be used only if there is catastrophic error and there is not a more appropriate code. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and for a REST binding a HTTP code of '500'.
invalid_filter_field An invalid filter field was supplied and so the filtering was not possible. No data has been reurned. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and for a REST binding a HTTP code of '400'.
invalid_selection_field An invalid selection field field was supplied and data filtering on the selection criteria was not possible. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and for a REST binding a HTTP code of '400'.
invaliddata This error condition may occur if a JSON request/response body contains well-formed (i.e. syntactically correct), but semantically erroneous, JSON instructions. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and a HTTP code of '422'.
server_busy The server is receiving too many requests. Retry at a later time. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and for a REST binding a HTTP code of '429'.
unauthorisedrequest The request was not correctly authorised. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and for a REST binding a HTTP code of '401'.
unknownobject The supplied identifier is unknown in the Service Provider and so the object could not be changed. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and for a REST binding a HTTP code of '404'.

6.4.6 imsx_SeverityEnum Vocabulary Description

The permitted vocabulary for the values for the Severity field. The data model for the "imsx_SeverityEnum" enumerated class is shown in Figure 6.4.6 and the accompanying vocabulary definition in Table 6.4.6.

UML diagram of the imsx_SeverityEnum class.

Figure 6.4.6 - imsx_SeverityEnum class definitions.

Table 6.4.6 Description of the "imsx_SeverityEnum" enumerated vocabulary terms.
Term Definition
error A significant error has occurred in processing the request and so the request was not completed (the Service Provider may not even have received the request).
status The request has been completed and a response was received from the Service Provider.
warning The request has only been partially completed. For an asynchronous service a further response should be expected.

toc | top

7. Link Data Definitions

This Section is NORMATIVE.

All of the link data for the relationships used within this Information Model are described in this Section. The syntax and semantics for this representation is described in Appendix A3.7.

7.1 CPResource Link Data Description

The description for the "CPResource" link data class is shown in Figure 7.1 and defined in Table 7.1.

UML diagram of the CPResource link data definition.

Figure 7.1 - CPResource link data definition.

Table 7.1 Description of the "CPResource" link data class.
Descriptor Definition
Target Class Name CPResource
Link Type CPResourceId - the link is to a resource contained within the manifest of an IMS Content Package/Common Cartridge/Thin Common Cartridge.
Link Sources The set of source classes that point to an object using this form of link are:
Source Attribute/
Characteristic Name
Not Applicable
Target Attribute/
Characteristic Name
CPResource.@identifier
Parent Class Name Not Applicable
Description This identifies that the type of link reference value for the associated identifier MUST have the same value as the identifier for the actual resource in the IMS Content Package/Common Cartridge manifest. It is the responsibility of the learning/content management systems to be able to reconcile this identifer mapping.

toc | top

8. Extending and Profiling the Service

This section is NOT NORMATIVE.

Proprietary extensions of the service are based upon two approaches:

It is NOT permitted to change the behavior of the current set of operations. Such changes MUST be supported by the creation of new operations.

8.1. Extending the Specification

8.1.1. Proprietary Operations

The definition of new operations should follow the same format as adopted herein. The new operations should be defined using a new interface type. Every operation must result in the return of a status code that describes the final state of the request on the target end system.

An example of creating such an extension is given in the accompanying Best Practices document [OR-IMPL-12].

8.1.2. Proprietary Data Elements

It is recognized that implementers may wish to extend the specification. The preferred mechanism for doing this is for implementers to use an extension space within the OneRoster data model, and then set their parsers to read those extension attributes. Extensions are ONLY permitted using the 'metadata' attribute within the 'Base' class (see Sub-section 5.1.1 for more details).

8.1.3. Proprietary Vocabulary Terms

In this version the ability to extend some of the enumerated vocabularies has been added: currently, ONLY the 'RoleEnum' vocabulary MAY be extended. Each proprietary term must start with the characters 'ext:'.

8.2. Profiling the Specification

This Service can be profiled. In general, Profiling is used to:

Valid Profiles must be restrictive i.e. optional features can be removed or constraints increased but new features must not be added. A Profile of this service is made by annotating the UML supplied with the documentation for the specification.

It is strongly recommended that a profile of this specification is undertaken either by, or with the close support, of IMS Global. However, no matter who is responsible for creating the profile artefacts (documents, XSDs, etc.), it is strongly recommended that the IMS specification tools are used. This will ensure that the artefacts are consistent with the base specifications and that useful support documentation is automatically produced e.g. creation of a document that summarises the differences between the base specification and the profile. Organizations wishing to produce a profile of this specification should contact Lisa Mattson (IMS Global Chief Operations Officer) at: lmattson@imsglobal.org.

toc | top

References

[I-BAT, 06] IMS Binding Auto-generation Toolkit (I-BAT), C.Smythe, IMS Global Learning Consortium Inc., July 2006.
[ISO 8601] ISO8601:2004 Data elements and interchange formats - Information interchange - Representation of dates and times, ISO, International Standards Organization (ISO), , 2000.
[OR-CERT-12] IMS OneRoster 1.2 Conformance and Certification Candidate Final Public Release, M.Richards, J.McGhee and C.Smythe, IMS Global Learning Consortium Inc., July 2021, https://www.imsglobal.org/spec/oneroster/v1p2/cert.
[OR-GBK-SM-12] IMS OneRoster 1.2 Gradebook Services Candidate Final Public Release, M.Richards, J.McGhee and C.Smythe, IMS Global Learning Consortium Inc., July 2021, https://www.imsglobal.org/spec/oneroster/v1p2/gradebook/info.
[OR-IMPL-12] IMS OneRoster 1.2 Best Practices and Implementation Guide Candidate Final Public Release, M.Richards, J.McGhee and C.Smythe, IMS Global Learning Consortium Inc., July 2021, https://www.imsglobal.org/spec/oneroster/v1p2/impl.
[OR-RES-RJ-12] IMS OneRoster 1.2 Resources REST/JSON Binding Candidate Final Public Release, M.Richards, J.McGhee and C.Smythe, IMS Global Learning Consortium Inc., July 2021, https://www.imsglobal.org/spec/oneroster/v1p2/resource/bind/rest.
[OR-ROS-SM-12] IMS OneRoster 1.2 Rostering Services Candidate Final Public Release, M.Richards, J.McGhee and C.Smythe, IMS Global Learning Consortium Inc., July 2021, https://www.imsglobal.org/spec/oneroster/v1p2/rostering/info.
[RFC 2119] Key words for use in RFCs to Indicate Requirement Levels, S. Bradner, IETF (RFC 2119), March 1997, https://www.ietf.org/rfc/rfc3066.txt.
[RFC 2617] HTTP Authentication: Basic and Digest Access Authentication, J. Franks, P. Hallam-Baker, J. Hostetler, S. Lawrence, P. Leach, A. Luotonen and L. Stewart, IETF (RFC 2167), 1999, https://tools.ietf.org/pdf/rfc2617.pdf.
[RFC 3066] Tags for the Identification of Languages, H.Alvestrand, IETF (RFC 3066), January 2001, https://www.ietf.org/rfc/rfc3066.txt.
[RFC 5849] OAuth Version 1.0, IETF, IETF (RFC 5849), April 2010, https://tools.ietf.org/pdf/rfc5849.pdf.
[RFC 6749] The OAuth 2.0 Authorization Framework, D.Hardt, IETF (RFC 6749), 2012, https://tools.ietf.org/pdf/rfc6749.pdf.
[RFC 6750] The OAuth 2.0 Authorization Framework: Bearer Token Usage, D.Hardt, IETF (RFC 6750), 2012, https://tools.ietf.org/pdf/rfc6750.pdf.
[Security, 21] IMS Security Framework 1.1, C.Smythe, N.Mills, C.Vervoort and M.Mckell, IMS Global Learning Consortium Inc., July 2021, https://www.imsglobal.org/spec/security/v1p1/.
[UNICODE, 16] UNICODE Collation Algorithm Version 9.0, M.Davis, K.Whistler and M.Scheer, Unicode Technical Standard #10, May 2016.
[VDEX, 04] IMS Vocbulary Definition Exchange (VDEX) 1.0, A.Cooper, IMS Global Learning Consortium, February 2004, https://www.imsglobal.org/vdex/vdexv1p0/imsvdex_infov1p0.html.

toc | top

Appendix A Modelling Concepts and Terms

This Appendix is NOT NORMATIVE.

A1 Behavior Descriptions Explanations

This section is NOT NORMATIVE.

A1.1 Service Model Diagrams

Table A1.1 provides the key to the descriptions of service model diagrams.

Table A1.1 The key to the descriptions of service model diagrams.
Feature Definition and Usage
Service Model Package Each synchronous or asynchronous service model description is enclosed in a UML Package that has the stereotype of « serviceModel » under which is the name of the service being described. A service must have at least one Interface (the breakdown of the service into the component transactions is a design decision).
Interface Class Each interface description is enclosed in a UML Package that has the stereotype of « Interface » under which is the name of the interface being described. An interface is a collection of operations that support a common set of transaction objectives. An interface must have at least one operation. An Interface class has no attributes.
Operation Description The behaviors provided by an interface are defined by the set of operations. Each operation must have a unique name and is accompanied by the set of parameters that are sent to the service (in) and those returned by the service (out). An operation can also have a formal return parameter whose form and usage depends upon the actual binding realisation. The description may also include a stereotype for the identification of the nature operation e.g. read, create, etc.

A1.2 Operation Descriptions

Table A1.2 provides the key to the descriptions of the operation tables.

Table A1.2 The key to the operation description tables.
Descriptor Definition
Name The name given to the operation being described. In the case of an interface, by definition, every operation has the scope value of global denoted by the "+" symbol before the name.
Stereotype Before the name of the operation there may be a stereotype classifier. This is used to provide information about the nature of the behavior of the operation. The permitted set of stereotype values and their meaning are:
  • « create » - indicates that a request is being made to create a new object/resource where the requester provides the associated unique identifier;
  • « createbp » - indicates that a request is being made to create a new object/resource where the responder provides the associated unique identifier;
  • « read » - indicates that a request is being made to read an existing object/resource;
  • « update » - indicates that a request is being made to update an existing object/resource i.e. an additive write;
  • « delete » - indicates that a request is being made to delete an existing object/resource;
  • « replace » - indicates that a request is being made to replace an existing object/resource i.e. a destructive write;
  • « query » - indicates that a request is being made to search for objects/resources according to a defined set of search criteria;
  • « publish » - indicates that a request is being made by a publisher in a publish and subscribe binding;
  • « subscribe » - indicates that a request is being made by a subscriber in a publish and subscribe binding.
Return Function Parameter The formal return parameter for the operation/method returned for the transaction request (the form in which this information is provided depends on the realisation of the binding). The description includes the name of the parameter and the data-type in the form "name:data-type" pair. The name/data-type provides a link to the associated interface data-type description in The Interface Data Model. In situations where there is no return function this entry will be set to "void"
Supplied (in) Parameters The list of parameters that are sent from the client to the end-service in the service request message. Each parameter description includes the name of the parameter and the data-type in the form "name:data-type" pair. The name/data-type provides a link to the associated interface data-type description in The Interface Data Model.
Supplied (out) Parameters The list of parameters that are returned from the end-service in the service response message. Each parameter description includes the name of the parameter and the data-type in the form "name:data-type" pair. The name/data-type provides a link to the associated interface data-type description in The Interface Data Model.
Behavior A description of the behavior of the operation.
Notes Further information on the behavior particularly in the context of the use of other operations and the relationship to the behaviors of those operations.

A2 Interface Descriptions Explanations

This section is NOT NORMATIVE.

A2.1 Parameter Model Diagrams

Table A2.1 provides the key to the descriptions of parameter data model diagrams.

Table A2.1 The key to the descriptions of parameter model diagrams.
Feature Definition and Usage
Data Model Package Each parameter data model description is enclosed in a UML Package that has the stereotype of « dataModel » under which is the name of the class being described.
DerivedType Class This is a class that is identified by the stereotype « DerivedType » under which is the name of the data-type. A derived class is one that is derived either from another derived class or a PrimitiveType class.
Enumeration Class This is a class that is identified by the stereotype « Enumeration » under which is the name of the enumeration data-type. The enumeration class consists of the list of tokens that are the permitted values of the assigned attribute.
Selection Class This is a class that is identified by the stereotype « Selection » under which is the name of the data-type. The selection means that only one of the listed attributes make occur in an instance. If this is an abstract class then multiple iterations of the instance may occur and the multiplicity of the attribute defines the constraints on the number of times the attribute can occur in the full instance.
Sequence Class This is a class that is identified by the stereotype « Sequence » under which is the name of the data-type. The sequence means that the listed attributes must occur only in the order of the attributes listed on the class. The associated multiplicity defines the number of times the attribute may occur consecutively in the instance.
Unordered Class This is a class that is identified by the stereotype « Unordered » under which is the name of the data-type. The unordering means that the listed attributes may occur in any order but the associated multiplicity for the attribute must be followed (when binding to XML this requires the use of Schematron rules to enforce the multiplicity).
Attribute Description Each class contains a set of attributes. Each attribute description consists of the scope, name, data-type and multiplicity (see Appendix A2.3 for a more complete description).
Composition Arrow This is an arrow with a filled diamond head to indicate that the child class is a composite structure of the parent class i.e. the child class only exists within the context of the parent class. This association allows complex structures to be constructed with common subcomponents.

A2.2 Class Descriptions

Table A2.2 provides the key to the descriptions of the parameter data class tables.

Table A2.2 The key to the descriptions of the data class tables.
Descriptor Definition
Class Name The name given to the class being described.
Class Type The nature of the class (for a parameter data-type this must not be an abstract class). This is described as a "Container [...]" with the value of "..." being (see Appendix A2.1 for the meaning of these values):
  • "DerivedType"
  • "Sequence"
  • "Selection"
  • "Unordered"
Parents This is the list of operations for which this class is a data-type for one or more of the parameters. Each entry is linked to the corresponding operation description.
Children Lists the set of attributes for this class (the only other permitted associations are generalizations). The list of children includes those that are grouped under a corresponding stereotyped attribute class. Each child is linked to the corresponding attribute description table. The nature of the relationship between the children is defined by the stereotype of the parent class i.e. the class type.
Description Contains descriptions relating to the class and its properties and relationships.

A2.3 Attribute Descriptions

Table A2.3 provides the key to the descriptions of the data attributes for the data classes for the operation parameters.

Table A2.3 The key to the descriptions of the data attribute tables.
Descriptor Definition
Attribute Name The name given to the attribute being described.
Data Type This is the data-type of the attribute. It can take many forms:
  • Class Name - the name of the Class (this is linked to the class definition);
  • Primtive Data-types - this is the same list as defined under the "Attribute and Characteristic" description (see later in this Appendix for these definitions).
Value Space The range of valid values for this class (including any default value). If the value space is unspecified, it is not known or is not important. This value space must be defined in terms of the associated data-type.
Scope This is the scope of the attribute with permitted values of:
  • Local - denoted by "-" and meaning the attribue has significance and access within the context of the parent class only;
  • Global - denoted by "+" and meaning that the attribute has global scoping (so must have a unique name) and can be accessed from anywhere.
Multiplicity A property of an attribute indicating the number of times it may be used or appear in a given class instance. The values of this property are expressed as a range or shorthand for a range using the notation:
  • "0..1" [optional; restricted]
  • "0..unbounded" [optional; unrestricted]
  • "1..1" [mandatory; restricted]
  • "1..unbounded" [mandatory; unrestricted]
Description Contains descriptions relating to the attribute and its values space.

A3 Data Model Descriptions Explanations

This section is NOT NORMATIVE.

A3.1 Data Model Diagrams

Table A3.1 provides the key to the descriptions of data model diagrams.

Table A3.1 The key to the descriptions of data model diagrams.
Feature Definition and Usage
Data Model Package Each data model description is enclosed in a UML Package that has the stereotype of « dataModel » under which is the name of the data model diagram being described. Only one logical data model can be described.
DerivedType Class This is a class that is identified by the stereotype « DerivedType » under which is the name of the data-type. A derived class is one that is derived either from another derived class or a PrimitiveType class.
Enumeration Class This is a class that is identified by the stereotype « Enumeration » under which is the name of the enumeration data-type. The enumeration class consists of the list of tokens that are the permitted values of the assigned attribute.
Enumerated List Class This is a class that is identified by the stereotype « EnumeratedList » under which is the name of the enumerated list data-type. The enumeration list class consists of the list of tokens that are the permitted values of the assigned attribute. A list of tokens is permitted using comma separation.
PrimitiveType Class This is a class that is identified by the stereotype « PrimitiveType » under which is the name of the primitive data-type. A PrimitiveType is one of the many base data-types on which a data model can be built (see Appendix A3.3 for the set of primitive types that are available).
Selection Class This is a class that is identified by the stereotype « Selection » under which is the name of the data-type. The selection means that only one of the listed attributes make occur in an instance. If this is an abstract class then multiple iterations of the instance may occur and the multiplicity of the attribute defines the constraints on the number of times the attribute can occur in the full instance. If the stereotype and associated name of the class are in italics this denotes the class is abstract.
Sequence Class This is a class that is identified by the stereotype « Sequence » under which is the name of the data-type. The sequence means that the listed attributes must occur only in the order of the attributes listed on the class. The associated multiplicity defines the number of times the attribute may occur consecutively in the instance. If the stereotype and associated name of the class are in italics this denotes the class is abstract.
Unordered Class This is a class that is identified by the stereotype « Unordered » under which is the name of the data-type. The unordering means that the listed attributes may occur in any order but the associated multiplicity for the attribute must be followed (when binding to XML this requires the use of Schematron rules to enforce the multiplicity). If the stereotype and associated name of the class are in italics this denotes the class is abstract.
List Class This is a class that is identified by the stereotype « List » under which is the name of the data-type. A list class is one in which the associated instance will consist of a list of objects that conform to the permitted data-types of the list (the superclasses for the list class). The terms in the list are separated by a space.
Union Class This is a class that is identified by the stereotype « Union » under which is the name of the data-type. A union class is one in which the associated instance will consist of a objects that conform to the any of the permitted data-types of the union (the superclasses for the union class).
Characteristic Description Many classes contain a set of characteristics (the set of characteristics are listed under the stereotype « Characteristics »). Each characteristic description consists of the scope, name, data-type and multiplicity (see Appendix A3.3 for a more complete description). Note that when bound to XSD/XML, a characteristic is mapped to an XML attribute.
Attribute Description Many classes contain a set of attributes (the set of attributes are listed under the stereotype « Attributes »). Each attribute description consists of the scope, name, data-type and multiplicity (see Appendix A3.3 for a more complete description). Note when bound to XSD/XML, an attribute is mapped to an XML element.
Aggregation Arrow This is an arrow with a white diamond head to indicate that the child class is an aggregate structure to the parent class i.e. the child class may exist without the context of the parent class. This association allows complex structures to be constructed with common subcomponents.
Composition Arrow This is an arrow with a filled diamond head to indicate that the child class is a composite structure of the parent class i.e. the child class only exists within the context of the parent class. This association allows complex structures to be constructed with common subcomponents.
Generalization Arrow This is an arrow with a white arrow head to indicate the class/superclass relationship. The arrow points in the direction of generality i.e. from the class to the super class.

toc | top

A3.2 Class Descriptions

Table A3.2 provides the key to the descriptions of the data class tables.

Table A3.2 The key to the descriptions of the data class tables.
Category Definition
Class Name The name given to the class being described.
Class Type The nature of the class. This is described as a "Container [...]" or "Abstract Container [...]". The value of "..." being (see Appendix A3.1 for the meaning of these values):
  • "DerivedType"
  • "List"
  • "Selection"
  • "Sequence"
  • "Union"
  • "Unordered"
If the container is also marked as "Mixed" then the children are permitted to include text as well as attributes.
Parents This is the list of classes that contain the class being described as either the type of a child characteristic or attribute. In the case of a Root Class the entry is also labelled as "Root Class".
Derived Classes The set of classes that are derived from this class (there may be none). The entries are linked to the corresponding class descriptions.
Super Classes The set of super classes from which the class being described is derived (there may be none). The entries are linked to the corresponding class descriptions.
Characteristics Lists the set of characteristics for this class. The list of characteristics includes those that are inherited. Each characteristic is linked to the corresponding characteristic description table.
Children Lists the set of attributes for this class (the only other permitted associations are generalizations). The list of children includes those attributes that are inherited. Each child entry is linked to the corresponding attribute description table. The nature of the relationship between the children is defined by the stereotype of the parent class i.e. the class type. If the child is in italics this denotes a reference to an abstract class and that an instance would NOT contain a child of that name but would be replaced by a complex set of children as defined by the associated abstract class.
Link Data Lists the set of attributes for this class that are used to provide links to other data objects in the data model. Many types of link references are available. This row is ONLY shown when the class contains at least one link data definition.
Description Contains descriptions relating to the class and its properties and relationships.

toc | top

A3.3 Attribute and Characteristic Descriptions

Table A3.3 provides the key to the descriptions of the data attributes/characteristics for the data classes.

Table A3.3 The key to the descriptions of the data attribute/characteristic tables.
Category Definition
Attribute Name or Characteristic Name The name given to the attribute or characteristic being described. If the name is in italics this denotes an abstract attribute or characteristic.
Data Type This is the data-type of the attribute or characteristic (if this is in italics it denotes an abstract class). The data-type can take many forms:
  • Class Name - the name of the Class (this is linked to the class definition elsewhere in this document);
  • Primitive Data-types from:-
    • AnyTypeLax - the namespace data-type i.e. defining data from any context (this is used for allowing any form of extension and the form of that extension is dependent on the type of binding);
    • AnyURI - the AnyURI data-type (absolute or relative URI);
    • Base - the base data-type for defining a base URI/URL link reference;
    • Boolean - the boolean data-type (with permitted values of "true" and "false");
    • Date - the date data-type (using the [ISO 8601] format);
    • DateTime - the date/time data-type (using the [ISO 8601] format);
    • Decimal - the decimal data-type (a variable precision number that is either positive or negative);
    • Double - the double data-type (double precision floating point number - 64bit);
    • Duration - the duration data-type (using the [ISO 8601] format)
    • Empty - the associated instance must be empty i.e. no child attributes;
    • Float - the float data-type (single precision floating point number - 32bit);
    • ID - the unique identifier data-type (the scope is constrained to the instance file);
    • IDREF - the reference to a previously defined unique identifier data-type (ID);
    • IDREFS - a list, whitespace separated, of references to a previously defined unique identifier data-type (ID);
    • Int - the int data-type with a numeric value from -2147483648 to 2147483647;
    • Integer - the integer data-type (this is derived from the "decimal" data-type i.e. no decimal places);
    • Language - the language data-type as defined in [RFC 5646];
    • Name - the Name data-type as per the XML 1.0 definition);
    • Namespace - the namespace data-type i.e. defining data from a context other than that as the default for the data model (this is used for importing other data models);
    • NamespaceLax - the namespace data-type i.e. defining data from a context other than that as the default for the data model (this is used for importing other data models but being lax on the validation);
    • NonNegativeInteger - the non-negative integer data-type (this is derived from the "integer" data-type) i.e. an integer that is zero or higher;
    • NCName - the NCName data-type (derived from the Name data-type i.e. non-colonized name);
    • NormalizedString - the normalized string data type (strings with line feeds, carriage returns and tab characters removed);
    • PositiveInteger - the positive integer data-type (this is derived from the "nonNegativeinteger" data-type) i.e. an integer that is one or higher;
    • String - the normalized string data type;
    • Time - the time data-type (using the [ISO 8601] format).
Value Space The range of valid values for this attribute/characteristic (including any default value). If the value space is unspecified, it is not known or is not important. This value space must be defined in terms of the associated data-type.
Scope This is the scope of the attribute/characteristic with permitted values of:
  • Local - denoted by "-" and meaning the attribute/characteristic has significance and access within the context of the parent class only;
  • Global - denoted by "+" and meaning that the attribute/characteristic has global scoping (so must have a unique name) and can be accessed from anywhere.
Multiplicity A property of an attribute/characteristic indicating the number of times it may be used or appear in a given class instance. The values of this property are expressed as a range or shorthand for a range using the notation:
  • "0..1" [optional; restricted]
  • "0..*" [optional; unrestricted]
  • "1" [mandatory; restricted]
  • "1..*" [mandatory; unrestricted]
Description Contains descriptions relating to the attribute/characteristic and its values space.
Link Data Contains the description of the link data definition. A link to the corresponding detailed link data description is supplied. This row is ONLY shown when the attribute/characteristice is a link data definition.

toc | top

A3.4 Enumerated Vocabulary Descriptions

Table A3.4 provides the key to the descriptions of the enumerated vocabulary classes. These are vocabularies that will be contained within the binding form itself. They are contained within a class that has a stereotype of either « Enumeration » or « EnumeratedList ».

Table A3.4 The key to the descriptions of the enumerated vocabulary tables.
Category Definition
Term The vocabulary token itself i.e. the vocabulary entry.
Definition The meaning of the term and how it should be used.

toc | top

A3.5 External Vocabulary Descriptions

Table A3.5 provides the key to the descriptions of the external vocabulary classes. These are vocabularies that will be contained in some independent format e.g. using the IMS VDEX [VDEX, 04].

Table A3.5 The key to the descriptions of the external vocabulary tables.
Category Definition
Term The vocabulary token itself i.e. the vocabulary entry.
Definition The meaning of the term and how it should be used. This consists of the "Caption" and "Description" of the vocabulary term. The caption is used to provide a human readable label for the term.

toc | top

A3.6 Import Class Descriptions

Table A3.6 provides the key to the descriptions of the import classes.

Table A3.6 The key to the descriptions of the imported class tables.
Category Definition
Import Class Name The name of the class.
Parent Classes The list of parent classes, and the associated children, that use this imported class. Each class and attribute name has a link to its corresponding tabular description in the information model.
Description The description of how the class is used within the data model.

toc | top

A3.7 Link Data Descriptions

Table A3.7 provides the key to the descriptions of the link data definitions.

Table A3.7 The key to the descriptions of the link data tables.
Category Definition
Target Class Name This is the name of the target class i.e. the destination point of the link reference.
Link Type This is the type of link that is being used. The types of link available are:
  • "SourcedId" - this link is through interoperability identifier for the target object i.e. the object can be obtained by using this sourceId with the corresponding service call;
  • "IntraParentClassId" - this link is between two attributes/characteristics that are contained within the same parent class;
  • "CPResourceId" - this link is to a resource contained within an IMS Content Package/IMS Common Cartridge/Thin Common Cartridge manifest. The reference value is that assigned to the "identifier" of the resource in the package/cartridge manifest;
  • "CASEItemId" - this link is to the learning objective description (contained within an IMS CASE Item definition).
Link Sources This is the set of classes that contain attributes/characteristics which use the link data defined by this entry. A link to the attribute/characteristic is provided.
Source Attribute This is the attribute/characteristic in the source object that contains the identifier of the target object (a characteristic name MUST start with an "@"). This will only be supplied if the pointer is contained within a substructure within the source object. If there is no source the statement "Not Applicable" will be displayed.
Target Attribute This is the attribute/characteristic in the target class which is the container for the identifier of the object being identified (a characteristic name MUST start with an "@"). It is the value for this identifier which MUST be supplied in the source object. For "CPResourceId" link types the fixed value of "@identifier" will be given. If there is no target the statement "Not Applicable" will be displayed.
Parent Class Name This is the name of the class that contains both the source and target attributes/characteristics. This value will only be supplied for the "IntraParentClassId" link types. If there is no parent class name the statement "Not Applicable" will be displayed.
Description The description of how the link data is used within the data model.

toc | top

A3.8 Common Data Model Persistent Identifier Descriptions

Table A3.8 provides the key to the descriptions of the common data model persistent identifier definitions.

Table A3.8 The key to the descriptions of the common data model persistent identifier tables.
Category Definition
Name This is the name of the data model component which has been assigned a common data model persistent identifier.
Type This is the type of link that is being used. The types of link available are:
  • "Class (...)" - a complex data model component i.e. it contains one or more properties;
  • "Property" - a property of a parent Class;
  • "Enumerated Vocabulary Term" - the term/token within an enumerated vocabulary
Persistent Identifier The common data model persistent identifier that has been assigned to this data model component. By definition, this is a unique (within the context of the IMS Common Data Model) and very long-lived identifier

toc | top

Appendix B Service Status Codes

This Section is NORMATIVE

When a behavior-based IMS service model is developed each operation is required to return status information. This status information provides contextual information about the completed success or otherwise of the operation. There are two types of status information that are available to the end-systems:

B1 Definition of the Status Codes

The status information for the business transactions is carried in a single status information object that contains the following sub-structures:

The interpretation of the "CodeMajor/Severity" behavior matrix is summarized in Table B1.1.

Table B1.1 Interpretation of the "CodeMajor/Severity" behavior matrix.
Severity CodeMajor
"Success" "Processing" "Failure" "Unsupported"
"Status" The transaction request has been completed successfully. The transaction request is being processed at the destination i.e. the request has been received and acknowledged. This combination is used in asynchronous services. The transaction request has failed. The detailed reason will be reported in the accompanying "codeMinor" fields. The destination service handler does not support the requested operation. This is the required default response for an unsupported operation by an implementation.
"Warning" Some of the request has been completed successfully e.g. partial data storage, etc. The request has been transmitted but acknowledgement of receipt at the destination has not been received. This combination is used in asynchronous services. Not permitted. Not permitted.
"Error" Not permitted. An error has been detected in the immediate transmission communications handler i.e. the message has not left the local end-system. There has been a failure in the end-to-end system communications mechanism and so the request has not been delivered. The destination service handler does not recognise the requested operation i.e. it is an unknown service extension.

B1.1 Definition of the "CodeMajor" Values

The set of codes used for the "codeMajor" status code field are defined in Table B1.2.

Table B1.2 Definition of the "CodeMajor" status code values.
Status Code Description
success Denotes that the request has been successfully completed. If the associated 'severity' value is 'warning' then the request has been partially successful i.e. best effort by the service provider. Other parts of the status information may provide more insight into a partial success response.
processing Denotes that the request is being processed at the destination or there has been a local transmission failure. This value is used in asynchronous services.
failure Denotes that the transaction request has failed. The detailed reason will be reported in the accompanying 'codeMinor' fields.
unsupported Denotes that the service provider does not support the requested operation. This is the required default response for an unsupported operation by an implementation.

B1.2 Definition of the "Severity" Values

The set of codes used for the "severity" status code field are defined in Table B1.3.

Table B1.3 Definition of the "Severity" status code values.
Status Code Description
status The request has been completed and a response was received from the Service Provider.
warning The request has only been partially completed. For an asynchronous service a further response should be expected.
wrror A significant error has occurred in processing the request and so the request was not completed (the Service Provider may not even have received the request).

B1.3 Definition of the "CodeMinor" Values

The set of codes used for the "codeMinor" status code field are defined in Table B1.4.

Table B1.4 Definition of the "CodeMinor" status code field values.
Status Code Description
createsuccess The request has been fully and successfully implemented by the Service Provider. For a REST binding this will have an HTTP code of '201' for a successful 'PUT' request.
deletesuccess The request has been fully and successfully implemented by the Service Provider. For a REST binding this will have an HTTP code of '204' for a successful 'DELETE' request.
forbidden This is used to indicate that the server can be reached and process the request but refuses to take any further action. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and for a REST binding a HTTP code of '403'.
internalservererror This should be used only if there is catastrophic error and there is not a more appropriate code. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and for a REST binding a HTTP code of '500'.
invaliddata This error condition may occur if a JSON request/response body contains well-formed (i.e. syntactically correct), but semantically erroneous, JSON instructions. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and a HTTP code of '422'.
invalidfilterfield An invalid filter field was supplied and so the filtering was not possible. No data has been reurned. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and for a REST binding a HTTP code of '400'.
invalidselectionfield An invalid selection field was supplied and data filtering on the selection criteria was not possible. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and for a REST binding a HTTP code of '400'.
invalidsortfield An invalid sort field was supplied and sorting was not possible. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and for a REST binding a HTTP code of '400'.
readsuccess The request has been fully and successfully implemented by the Service Provider. For a REST binding this will have an HTTP code of '200' for a successful 'GET' request.
replacesuccess The request has been fully and successfully implemented by the Service Provider. For a REST binding this will have an HTTP code of '201' for a successful 'PUT' request.
serverbusy The server is receiving too many requests. Retry at a later time. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and for a REST binding a HTTP code of '429'.
unauthorisedrequest The request was not correctly authorised. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and for a REST binding a HTTP code of '401'.
unknownobject The supplied identifier is unknown in the Service Provider and so the object could not be changed. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and for a REST binding a HTTP code of '404'.
unsupported Denotes that the service provider does not support the requested operation. This is the required default response for an unsupported operation by an implementation. This would be accompanied by the 'codeMajor/severity' values of 'failure/error' and for a REST binding a HTTP code of '500'.

toc | top

About this Document

Title: IMS OneRoster Resources Service v1.2
Editors: Colin Smythe (IMS Global, UK)

Co-chairs: Matt Richards (Infinite Campus, USA)

Version: 1.0
Version Date: 1st July 2021
Status: IMS Candidate Final Public
Summary: This is the OneRoster 1.2 Resources Service specification. It defines the exchange of the identification of the resources that are linked to classes, courses and users. This service is made available as a REST/JSON based binding to support resources allocation to classes and courses data exchange.

Revision Information: The first release of the OneRoster 1.2 Resources Service specification based upon the I-BAT. Support for the allocation of resources to users has been added in this version.
Purpose: For public adoption.
Document Location: https://www.imsglobal.org/spec/oneroster/v1p2/resource/info

toc | top

List of Contributors

The following individuals contributed to the development of this document:

Eric Adams Kimono (USA)
Arthur Barstow McGraw-Hill Education (USA)
Vijay Dhanaraj Classlink (USA)
Linda Feng Unicon (USA)
Viktor Haag Desire2Learn (Canada)
Richard Heim LearningMate (USA)
Oxana Jurosevic Instructure (USA)
Mike Kastraa Desire2Learn
Lisa Mattson IMS Global (USA)
David Mayes Gwinnett County Schools (USA)
Joshua McGhee IMS Global (USA)
Phil Nicholls IMS Global (UK)
Padraig O'hiceadha HMH (UK)
George Perreault Classlink (USA)
Matthew Richards Infinite Campus (USA)
Kurt Rompot Pearson (USA)
Marc Sheftel Pearson (USA)
Colin Smythe IMS Global (UK)
Konrad Stimeling K12 Inc (USA)
Matt Vella Schoology (USA)
TJ Vering Microsoft (USA)
Stanley Watts Classlink (USA)
Mike Zackerson Instructure (USA)

toc | top

Revision History

Version No. Release Date Comments
Final Release 1.0 / Docment 1.0 1st July, 2015 First release of the OneRoster Service specification.
Final Release 1.1 / Docment 1.0 1st November, 2016 This second release includes new operations to create and delete single objects, support for the exchange of Result, LineItem, Category and Resource objects.
Candidate Final Public 1.2 / Docment 1.0 1st July 2021 This is the first release of the OneRoster 1.2 Rostering Service as a standalone document. The new functionality added is support for the exchange of resources for users using the new endpoint getResourcesForUser().

toc | top

IMS Global Learning Consortium, Inc. ("IMS Global") is publishing the information contained in this document ("Specification") for purposes of scientific, experimental, and scholarly collaboration only.

IMS Global makes no warranty or representation regarding the accuracy or completeness of the Specification.

This material is provided on an "As Is" and "As Available" basis.

The Specification is at all times subject to change and revision without notice.

It is your sole responsibility to evaluate the usefulness, accuracy, and completeness of the Specification as it relates to you.

IMS Global would appreciate receiving your comments and suggestions.

Please contact IMS Global through our website at http://www.imsglobal.org.

Please refer to Document Name: IMS OneRoster Resources Service v1.2

Date: 1st July 2021

toc | top
