The definition of the "assessmentResult" root attribute is shown in Table 2.2.1.

The data model for the "AssessmentResult" root class is shown in Figure 2.3.1 and the accompanying definition in Table 2.3.1.

Figure 2.3.1 - AssessmentResult class definitions.

The description of the "context" attribute for the "AssessmentResult" root class is given in Table 2.3.1.1.

The description of the "testResult" attribute for the "AssessmentResult" root class is given in Table 2.3.1.2.

The description of the "itemResult" attribute for the "AssessmentResult" root class is given in Table 2.3.1.3.

The data model for the "CandidateResponse" class is shown in Figure 2.4.1 and the accompanying definition in Table 2.4.1.

Figure 2.4.1 - CandidateResponse class definitions.

The description of the "value" attribute for the "CandidateResponse" class is given in Table 2.4.1.1.

The data model for the "Context" class is shown in Figure 2.4.2 and the accompanying definition in Table 2.4.2.

Figure 2.4.2 - Context class definitions.

The description of the "sourcedId" characteristic for the "Context" class is given in Table 2.4.2.1.

The description of the "sessionIdentifier" attribute for the "Context" class is given in Table 2.4.2.2.

The data model for the "ContextTemplateVariable" class is shown in Figure 2.4.3 and the accompanying definition in Table 2.4.3.

Figure 2.4.3 - ContextTemplateVariable class definitions.

The description of the "identifier" characteristic for the "ContextTemplateVariable" class is given in Table 2.4.3.1.

The description of the "cardinality" characteristic for the "ContextTemplateVariable" class is given in Table 2.4.3.2.

The description of the "baseType" characteristic for the "ContextTemplateVariable" class is given in Table 2.4.3.3.

The description of the "value" attribute for the "ContextTemplateVariable" class is given in Table 2.4.3.4.

The data model for the "CorrectResponse" class is shown in Figure 2.4.4 and the accompanying definition in Table 2.4.4.

Figure 2.4.4 - CorrectResponse class definitions.

The description of the "interpretation" characteristic for the "CorrectResponse" class is given in Table 2.4.4.1.

The description of the "value" attribute for the "CorrectResponse" class is given in Table 2.4.4.2.

The data model for the "ItemResult" class is shown in Figure 2.4.5 and the accompanying definition in Table 2.4.5.

Figure 2.4.5 - ItemResult class definitions.

The description of the "identifier" characteristic for the "ItemResult" class is given in Table 2.4.5.1.

The description of the "sequenceIndex" characteristic for the "ItemResult" class is given in Table 2.4.5.2.

The description of the "datestamp" characteristic for the "ItemResult" class is given in Table 2.4.5.3.

The description of the "sessionStatus" characteristic for the "ItemResult" class is given in Table 2.4.5.4.

The description of the "itemVariable" attribute for the "ItemResult" class is given in Table 2.4.5.5.

The description of the "candidateComment" attribute for the "ItemResult" class is given in Table 2.4.5.6.

The description of the "support" attribute for the "ItemResult" class is given in Table 2.4.5.7.

The data model for the "OutcomeInformation" class is shown in Figure 2.4.6 and the accompanying definition in Table 2.4.6.

Figure 2.4.6 - OutcomeInformation class definitions.

The description of the "extensions" attribute for the "OutcomeInformation" class is given in Table 2.4.6.1.

The data model for the "OutcomeVariable" class is shown in Figure 2.4.7 and the accompanying definition in Table 2.4.7.

Figure 2.4.7 - OutcomeVariable class definitions.

The description of the "identifier" characteristic for the "OutcomeVariable" class is given in Table 2.4.7.1.

The description of the "cardinality" characteristic for the "OutcomeVariable" class is given in Table 2.4.7.2.

The description of the "baseType" characteristic for the "OutcomeVariable" class is given in Table 2.4.7.3.

The description of the "view" characteristic for the "OutcomeVariable" class is given in Table 2.4.7.4.

The description of the "interpretation" characteristic for the "OutcomeVariable" class is given in Table 2.4.7.5.

The description of the "longInterpretation" characteristic for the "OutcomeVariable" class is given in Table 2.4.7.6.

The description of the "normalMaximum" characteristic for the "OutcomeVariable" class is given in Table 2.4.7.7.

The description of the "normalMinimum" characteristic for the "OutcomeVariable" class is given in Table 2.4.7.8.

The description of the "masteryValue" characteristic for the "OutcomeVariable" class is given in Table 2.4.7.9.

The description of the "external-scored" characteristic for the "OutcomeVariable" class is given in Table 2.4.7.10.

The description of the "variable-identifier-ref" characteristic for the "OutcomeVariable" class is given in Table 2.4.7.11.

The description of the "value" attribute for the "OutcomeVariable" class is given in Table 2.4.7.12.

The description of the "outcomeInformation" attribute for the "OutcomeVariable" class is given in Table 2.4.7.13.

The data model for the "ResponseVariable" class is shown in Figure 2.4.8 and the accompanying definition in Table 2.4.8.

Figure 2.4.8 - ResponseVariable class definitions.

The description of the "identifier" characteristic for the "ResponseVariable" class is given in Table 2.4.8.1.

The description of the "cardinality" characteristic for the "ResponseVariable" class is given in Table 2.4.8.2.

The description of the "baseType" characteristic for the "ResponseVariable" class is given in Table 2.4.8.3.

The description of the "choiceSequence" characteristic for the "ResponseVariable" class is given in Table 2.4.8.4.

The description of the "scoreStatus" characteristic for the "ResponseVariable" class is given in Table 2.4.8.5.

The description of the "answeredStatus" characteristic for the "ResponseVariable" class is given in Table 2.4.8.6.

The description of the "correctResponse" attribute for the "ResponseVariable" class is given in Table 2.4.8.7.

The description of the "candidateResponse" attribute for the "ResponseVariable" class is given in Table 2.4.8.8.

The data model for the "TestResult" class is shown in Figure 2.4.9 and the accompanying definition in Table 2.4.9.

Figure 2.4.9 - TestResult class definitions.

The description of the "identifier" characteristic for the "TestResult" class is given in Table 2.4.9.1.

The description of the "datestamp" characteristic for the "TestResult" class is given in Table 2.4.9.2.

The description of the "itemVariable" attribute for the "TestResult" class is given in Table 2.4.9.3.

The description of the "support" attribute for the "TestResult" class is given in Table 2.4.9.4.

The data model for the "ItemVariable" class is shown in Figure 2.5.1 and the accompanying definition in Table 2.5.1

Figure 2.5.1 - ItemVariable class definitions.

The description of the "responseVariable" attribute for the "ItemVariable" class is given in Table 2.5.1.1.

The description of the "templateVariable" attribute for the "ItemVariable" class is given in Table 2.5.1.2.

The description of the "outcomeVariable" attribute for the "ItemVariable" class is given in Table 2.5.1.3.

The description of the "contextVariable" attribute for the "ItemVariable" class is given in Table 2.5.1.4.

The data model for the "DateTime" class is shown in Figure 2.6.1 and the accompanying definition in Table 2.6.1.

Figure 2.6.1 - DateTime class definitions.

The description of the "pattern" attribute for the "DateTime" class is given in Table 2.6.1.

The data model for the "Identifier" class is shown in Figure 2.6.2 and the accompanying definition in Table 2.6.2.

Figure 2.6.2 - Identifier class definitions.

The data model for the "SessionIdentifier" class is shown in Figure 2.6.3 and the accompanying definition in Table 2.6.3.

Figure 2.6.3 - SessionIdentifier class definitions.

The description of the "sourceID" characteristic for the "SessionIdentifier" class is given in Table 2.6.3.1.

The description of the "identifier" characteristic for the "SessionIdentifier" class is given in Table 2.6.3.2.

The data model for the "Support" class is shown in Figure 2.6.4 and the accompanying definition in Table 2.6.4.

Figure 2.6.4 - Support class definitions.

The description of the "name" characteristic for the "Support" class is given in Table 2.6.4.1.

The description of the "assignment" characteristic for the "Support" class is given in Table 2.6.4.2.

The description of the "value" characteristic for the "Support" class is given in Table 2.6.4.3.

The description of the "language" characteristic for the "Support" class is given in Table 2.6.4.4.

The data model for the "UniqueIdentifierRef" class is shown in Figure 2.6.5 and the accompanying definition in Table 2.6.5.

Figure 2.6.5 - UniqueIdentifierRef class definitions.

The data model for the "Value" class is shown in Figure 2.6.6 and the accompanying definition in Table 2.6.6.

Figure 2.6.6 - Value class definitions.

The description of the "fieldIdentifier" characteristic for the "Value" class is given in Table 2.6.6.1.

The description of the "baseType" characteristic for the "Value" class is given in Table 2.6.6.2.

This is the definition for the set of permitted values for the 'answeredStatus' attribute for the 'ItemResult' class. The data model for the "AnsweredStatusEnum" enumerated class is shown in Figure 2.7.1 and the accompanying vocabulary definition in Table 2.7.1.

Figure 2.7.1 - AnsweredStatusEnum class definitions.

The permitted set of values for the scoping of a support feature. The data model for the "AssignmentEnum" enumerated class is shown in Figure 2.7.2 and the accompanying vocabulary definition in Table 2.7.2.

Figure 2.7.2 - AssignmentEnum class definitions.

A base-type is simply a description of a set of atomic values (atomic to this specification). Note that several of the baseTypes used to define the runtime data model have identical definitions to those of the basic data types used to define the values for attributes in the specification itself. The use of an enumeration to define the set of baseTypes used in the runtime model, as opposed to the use of classes with similar names, is designed to help distinguish between these two distinct levels of modeling. The data model for the "BaseTypeEnum" enumerated class is shown in Figure 2.7.3 and the accompanying vocabulary definition in Table 2.7.3.

Figure 2.7.3 - BaseTypeEnum class definitions.

Figure 2.7.4 - CardinalityEnum class definitions.

Identifies the set of modes for the external scoring of the Item. The data model for the "ExternalScoredEnum" enumerated class is shown in Figure 2.7.5 and the accompanying vocabulary definition in Table 2.7.5.

Figure 2.7.5 - ExternalScoredEnum class definitions.

This is the set of permitted values for the 'scoreStatus' attribute for the ItemResult class. The data model for the "ScoreStatusEnum" enumerated class is shown in Figure 2.7.6 and the accompanying vocabulary definition in Table 2.7.6.

Figure 2.7.6 - ScoreStatusEnum class definitions.

The session status is used to keep track of the status of the item variables in an item session. The data model for the "SessionStatusEnum" enumerated class is shown in Figure 2.7.7 and the accompanying vocabulary definition in Table 2.7.7.

Figure 2.7.7 - SessionStatusEnum class definitions.

The data model for the "IdentifierList" class is shown in Figure 2.8.1 and the accompanying definition in Table 2.8.1.

Figure 2.8.1 - IdentifierList class definitions.

Figure 2.9.1 - ViewEnum class definitions.

This Section is NOT NORMATIVE.

The UML/XSD Mapping for the "AssessmentResult" Root Class is given in Table 3.2.2.1.

The UML/XSD Mapping for the "CandidateResponse" Class is given in Table 3.2.3.1.

The UML/XSD Mapping for the "Context" Class is given in Table 3.2.3.2.

The UML/XSD Mapping for the "ContextTemplateVariable" Class is given in Table 3.2.3.3.

The UML/XSD Mapping for the "CorrectResponse" Class is given in Table 3.2.3.4.

The UML/XSD Mapping for the "ItemResult" Class is given in Table 3.2.3.5.

The UML/XSD Mapping for the "OutcomeInformation" Class is given in Table 3.2.3.6.

The UML/XSD Mapping for the "OutcomeVariable" Class is given in Table 3.2.3.7.

The UML/XSD Mapping for the "ResponseVariable" Class is given in Table 3.2.3.8.

The UML/XSD Mapping for the "TestResult" Class is given in Table 3.2.3.9.

The UML/XSD Mapping for the "DateTime" Derived Class is given in Table 3.2.4.1.

The UML/XSD Mapping for the "Identifier" Derived Class is given in Table 3.2.4.2.

The UML/XSD Mapping for the "SessionIdentifier" Derived Class is given in Table 3.2.4.3.

The UML/XSD Mapping for the "Support" Derived Class is given in Table 3.2.4.4.

The UML/XSD Mapping for the "UniqueIdentifierRef" Derived Class is given in Table 3.2.4.5.

The UML/XSD Mapping for the "Value" Derived Class is given in Table 3.2.4.6.

There are no union class definitions.

This Section is NORMATIVE.

There are no imported classes.

This Section is NORMATIVE.

The XSD description for the "assessmentResult" Root Element is given in Table 3.4.1.1.

Table 3.4.1.1 XSD description for the "assessmentResult" Root Element.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Diagram
Type	AssessmentResultDType
Properties	Content simple MinOccurs 1 MaxOccurs 1
Model	context{1..1}, testResult{0..1}, itemResult{0..*}
Attributes	None.
Source	<xs:element name="assessmentResult" type="AssessmentResultDType" />

There are no global elements.

There are no attribute groups.

The XSD description for the "AssessmentResultDType" Root ComplexType is given in Table 3.4.4.1.

Table 3.4.4.1 XSD description for the "AssessmentResultDType" Root Complex Type.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Annotations	This is the root class to contain the assessment result data. An Assessment Result is used to report the results of a candidate's interaction with a test and/or one or more items attempted. Information about the test is optional, in some systems it may be possible to interact with items that are not organized into a test at all. For example, items that are organized with learning resources and presented individually in a formative context.
Diagram
Properties	Abstract false Mixed false
Used by	Root Elements assessmentResult
Model	context{1..1}, testResult{0..1}, itemResult{0..*}
Attributes	None.
Source	<xs:complexType name="AssessmentResultDType" abstract="false" mixed="false"> <xs:sequence> <xs:element name="context" type="ContextDType" minOccurs="1" maxOccurs="1" /> <xs:element name="testResult" type="TestResultDType" minOccurs="0" maxOccurs="1" /> <xs:element name="itemResult" type="ItemResultDType" minOccurs="0" maxOccurs="unbounded" /> </xs:sequence> </xs:complexType>

The XSD description for the "context" Local Element is given in the Table below.

Table - XSD description for the "context/AssessmentResultDType" Local Element.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Diagram
Type	ContextDType
Properties	Content complex MinOccurs 1 MaxOccurs 1 Mixed false
Model	sessionIdentifier{0..*}
Attributes	QName Type Inherited Scope Use Default sourcedId IdentifierDType No Local Optional -
Source	<xs:element name="context" type="ContextDType" minOccurs="1" maxOccurs="1" />

The XSD description for the "testResult" Local Element is given in the Table below.

Table - XSD description for the "testResult/AssessmentResultDType" Local Element.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Diagram
Type	TestResultDType
Properties	Content complex MinOccurs 0 MaxOccurs 1 Mixed false
Model	( responseVariable{1..1} | templateVariable{1..1} | outcomeVariable{1..1} | contextVariable{1..1} ){0..*}, support{0..*}
Attributes	QName Type Inherited Scope Use Default identifier IdentifierDType No Local Required - datestamp DateTimeDType No Local Required -
Source	<xs:element name="testResult" type="TestResultDType" minOccurs="0" maxOccurs="1" />

The XSD description for the "itemResult" Local Element is given in the Table below.

Table - XSD description for the "itemResult/AssessmentResultDType" Local Element.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Diagram
Type	ItemResultDType
Properties	Content complex MinOccurs 0 MaxOccurs unbounded Mixed false
Model	( responseVariable{1..1} | templateVariable{1..1} | outcomeVariable{1..1} | contextVariable{1..1} ){0..*}, candidateComment{0..1}, support{0..*}
Attributes	QName Type Inherited Scope Use Default identifier IdentifierDType No Local Required - sequenceIndex xs:integer No Local Optional - datestamp DateTimeDType No Local Required - sessionStatus [ Enumeration ] No Local Required -
Source	<xs:element name="itemResult" type="ItemResultDType" minOccurs="0" maxOccurs="unbounded" />

The XSD description for the "CandidateResponseDType" Core ComplexType is given in Table 3.4.5.1.

Table 3.4.5.1 XSD description for the "CandidateResponseDType" Core Complex Type.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Annotations	The response given by the candidate.
Diagram
Properties	Abstract false Mixed false
Used by	Elements candidateResponse/ResponseVariableDType
Model	value{0..*}
Attributes	None.
Source	<xs:complexType name="CandidateResponseDType" abstract="false" mixed="false"> <xs:sequence> <xs:element name="value" type="ValueDType" minOccurs="0" maxOccurs="unbounded" /> </xs:sequence> </xs:complexType>

The XSD description for the "value" Local Element is given in the Table below.

Table - XSD description for the "value/CandidateResponseDType" Local Element.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Diagram
Type	ValueDType
Properties	Content simple MinOccurs 0 MaxOccurs unbounded
Model	N/A
Attributes	QName Type Inherited Scope Use Default fieldIdentifier IdentifierDType No Local Optional - baseType [ Enumeration ] No Local Optional -
Source	<xs:element name="value" type="ValueDType" minOccurs="0" maxOccurs="unbounded" />

The XSD description for the "ContextDType" Core ComplexType is given in Table 3.4.5.2.

Table 3.4.5.2 XSD description for the "ContextDType" Core Complex Type.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Annotations	This is the context for the 'assessmentResult'. It provides the corresponding set of identifiers.
Diagram
Properties	Abstract false Mixed false
Used by	Elements context/AssessmentResultDType
Model	sessionIdentifier{0..*}
Attributes	QName Type Inherited Scope Use Default sourcedId IdentifierDType No Local Optional -
Source	<xs:complexType name="ContextDType" abstract="false" mixed="false"> <xs:sequence> <xs:element name="sessionIdentifier" type="SessionIdentifierDType" minOccurs="0" maxOccurs="unbounded" /> </xs:sequence> <xs:attribute name="sourcedId" use="optional" type="IdentifierDType" /> </xs:complexType>

The XSD description for the "sourcedId" Local Attribute is given in the Table below.

<xs:attribute name="sourcedId" use="optional" type="IdentifierDType" />


The XSD description for the "sessionIdentifier" Local Element is given in the Table below.

Table - XSD description for the "sessionIdentifier/ContextDType" Local Element.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Diagram
Type	SessionIdentifierDType
Type Hierarchy	EmptyPrimitiveTypeDType ^---SessionIdentifierDType
Properties	Content simple MinOccurs 0 MaxOccurs unbounded
Model	Empty
Attributes	QName Type Inherited Scope Use Default sourceID xs:anyURI No Local Required - identifier IdentifierDType No Local Required -
Source	<xs:element name="sessionIdentifier" type="SessionIdentifierDType" minOccurs="0" maxOccurs="unbounded" />

The XSD description for the "ContextTemplateVariableDType" Core ComplexType is given in Table 3.4.5.3.

Table 3.4.5.3 XSD description for the "ContextTemplateVariableDType" Core Complex Type.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Annotations	The Item result information related to a Template or a Context Variable.
Diagram
Properties	Abstract false Mixed false
Used by	Elements contextVariable/ItemResultDType, contextVariable/TestResultDType, templateVariable/ItemResultDType, templateVariable/TestResultDType
Model	value{0..*}
Attributes	QName Type Inherited Scope Use Default identifier IdentifierDType No Local Required - cardinality [ Enumeration ] No Local Required - baseType [ Enumeration ] No Local Optional -
Source	<xs:complexType name="ContextTemplateVariableDType" abstract="false" mixed="false"> <xs:sequence> <xs:element name="value" type="ValueDType" minOccurs="0" maxOccurs="unbounded" /> </xs:sequence> <xs:attribute name="identifier" use="required" type="IdentifierDType" /> <xs:attribute name="cardinality" use="required"> <xs:simpleType> <xs:annotation> <xs:documentation source="documentation"> An expression or itemVariable can either be single-valued or multi-valued. A multi-valued expression (or variable) is called a container. A container contains a list of values, th- is list may be empty in which case it is treated as NULL. All the values in a multiple or ordered container are drawn from the same value set, however, containers may contain mult- iple occurrences of the same value. In other words, [A,B,B,C] is an acceptable value for a container. A container with cardinality multiple and value [A,B,C] is equivalent to a sim- ilar one with value [C,B,A] whereas these two values would be considered distinct for con- tainers with cardinality ordered. When used as the value of a response variable this dist- inction is typified by the difference between selecting choices in a multi-response multi- -choice task and ranking choices in an order objects task. In the language of [ISO 11404] a container with multiple cardinality is a "bag-type", a container with ordered cardinali- ty is a "sequence-type" and a container with record cardinality is a "record-type". The r- ecord container type is a special container that contains a set of independent values each identified by its own identifier and having its own base-type. This specification does not make use of the record type directly however it is provided to enable customInteractions to manipulate more complex responses and customOperators to return more complex values, in addition to the use for detailed information about numeric responses described in the str- ingInteraction abstract class. </xs:documentation> </xs:annotation> <xs:restriction base="xs:string"> <xs:enumeration value="multiple" /> <xs:enumeration value="ordered" /> <xs:enumeration value="record" /> <xs:enumeration value="single" /> </xs:restriction> </xs:simpleType> </xs:attribute> <xs:attribute name="baseType" use="optional"> <xs:simpleType> <xs:annotation> <xs:documentation source="documentation"> A base-type is simply a description of a set of atomic values (atomic to this specificati- on). Note that several of the baseTypes used to define the runtime data model have identi- cal definitions to those of the basic data types used to define the values for attributes in the specification itself. The use of an enumeration to define the set of baseTypes used in the runtime model, as opposed to the use of classes with similar names, is designed to help distinguish between these two distinct levels of modeling. </xs:documentation> </xs:annotation> <xs:restriction base="xs:string"> <xs:enumeration value="boolean" /> <xs:enumeration value="directedPair" /> <xs:enumeration value="duration" /> <xs:enumeration value="file" /> <xs:enumeration value="float" /> <xs:enumeration value="identifier" /> <xs:enumeration value="integer" /> <xs:enumeration value="pair" /> <xs:enumeration value="point" /> <xs:enumeration value="string" /> <xs:enumeration value="uri" /> </xs:restriction> </xs:simpleType> </xs:attribute> </xs:complexType>

The XSD description for the "identifier" Local Attribute is given in the Table below.

<xs:attribute name="identifier" use="required" type="IdentifierDType" />


The XSD description for the "cardinality" Local Attribute is given in the Table below.

<xs:attribute name="cardinality" use="required">
    <xs:simpleType>
        <xs:restriction base="xs:string">
            <xs:enumeration value="multiple" />
            <xs:enumeration value="ordered" />
            <xs:enumeration value="record" />
            <xs:enumeration value="single" />
        </xs:restriction>
    </xs:simpleType>
</xs:attribute>


The XSD description for the "baseType" Local Attribute is given in the Table below.

<xs:attribute name="baseType" use="optional">
    <xs:simpleType>
        <xs:restriction base="xs:string">
            <xs:enumeration value="boolean" />
            <xs:enumeration value="directedPair" />
            <xs:enumeration value="duration" />
            <xs:enumeration value="file" />
            <xs:enumeration value="float" />
            <xs:enumeration value="identifier" />
            <xs:enumeration value="integer" />
            <xs:enumeration value="pair" />
            <xs:enumeration value="point" />
            <xs:enumeration value="string" />
            <xs:enumeration value="uri" />
        </xs:restriction>
    </xs:simpleType>
</xs:attribute>


The XSD description for the "value" Local Element is given in the Table below.

Table - XSD description for the "value/ContextTemplateVariableDType" Local Element.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Diagram
Type	ValueDType
Properties	Content simple MinOccurs 0 MaxOccurs unbounded
Model	N/A
Attributes	QName Type Inherited Scope Use Default fieldIdentifier IdentifierDType No Local Optional - baseType [ Enumeration ] No Local Optional -
Source	<xs:element name="value" type="ValueDType" minOccurs="0" maxOccurs="unbounded" />

The XSD description for the "CorrectResponseDType" Core ComplexType is given in Table 3.4.5.4.

Table 3.4.5.4 XSD description for the "CorrectResponseDType" Core Complex Type.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Annotations	The correct response may be output as part of the report if desired. Systems are not limited to reporting correct responses declared in responseDeclarations. For example, a correct response may be set by a templateRule or may simply have been suppressed from the declaration passed to the delivery engine e.g. for security.
Diagram
Properties	Abstract false Mixed false
Used by	Elements correctResponse/ResponseVariableDType
Model	value{1..*}
Attributes	QName Type Inherited Scope Use Default interpretation xs:string No Local Optional -
Source	<xs:complexType name="CorrectResponseDType" abstract="false" mixed="false"> <xs:sequence> <xs:element name="value" type="ValueDType" minOccurs="1" maxOccurs="unbounded" /> </xs:sequence> <xs:attribute name="interpretation" use="optional" type="xs:string" /> </xs:complexType>

The XSD description for the "interpretation" Local Attribute is given in the Table below.

<xs:attribute name="interpretation" use="optional" type="xs:string" />


The XSD description for the "value" Local Element is given in the Table below.

Table - XSD description for the "value/CorrectResponseDType" Local Element.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Diagram
Type	ValueDType
Properties	Content simple MinOccurs 1 MaxOccurs unbounded
Model	N/A
Attributes	QName Type Inherited Scope Use Default fieldIdentifier IdentifierDType No Local Optional - baseType [ Enumeration ] No Local Optional -
Source	<xs:element name="value" type="ValueDType" minOccurs="1" maxOccurs="unbounded" />

The XSD description for the "ItemResultDType" Core ComplexType is given in Table 3.4.5.5.

Table 3.4.5.5 XSD description for the "ItemResultDType" Core Complex Type.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Annotations	The result of an item session is reported with an itemResult. A report may contain multiple results for the same instance of an item representing multiple attempts, progression through an adaptive item or even more detailed tracking. In these cases, each item result must have a different datestamp.
Diagram
Properties	Abstract false Mixed false
Used by	Elements itemResult/AssessmentResultDType
Model	( responseVariable{1..1} | templateVariable{1..1} | outcomeVariable{1..1} | contextVariable{1..1} ){0..*}, candidateComment{0..1}, support{0..*}
Attributes	QName Type Inherited Scope Use Default identifier IdentifierDType No Local Required - sequenceIndex xs:integer No Local Optional - datestamp DateTimeDType No Local Required - sessionStatus [ Enumeration ] No Local Required -
Source	<xs:complexType name="ItemResultDType" abstract="false" mixed="false"> <xs:sequence> <xs:choice minOccurs="0" maxOccurs="unbounded"> <xs:element name="responseVariable" type="ResponseVariableDType" minOccurs="1" maxOccurs="1"/> <xs:element name="templateVariable" type="ContextTemplateVariableDType" minOccurs="1" maxOccurs="1"/> <xs:element name="outcomeVariable" type="OutcomeVariableDType" minOccurs="1" maxOccurs="1"/> <xs:element name="contextVariable" type="ContextTemplateVariableDType" minOccurs="1" maxOccurs="1"/> </xs:choice> <xs:element name="candidateComment" type="xs:string" minOccurs="0" maxOccurs="1" /> <xs:element name="support" type="SupportDType" minOccurs="0" maxOccurs="unbounded" /> </xs:sequence> <xs:attribute name="identifier" use="required" type="IdentifierDType" /> <xs:attribute name="sequenceIndex" use="optional" type="xs:integer" /> <xs:attribute name="datestamp" use="required" type="DateTimeDType" /> <xs:attribute name="sessionStatus" use="required"> <xs:simpleType> <xs:annotation> <xs:documentation source="documentation"> The session status is used to keep track of the status of the item variables in an item s- ession. </xs:documentation> </xs:annotation> <xs:restriction base="xs:string"> <xs:enumeration value="final" /> <xs:enumeration value="initial" /> <xs:enumeration value="pendingExternalScoring" /> <xs:enumeration value="pendingResponseProcessing" /> <xs:enumeration value="pendingSubmission" /> </xs:restriction> </xs:simpleType> </xs:attribute> </xs:complexType>

The XSD description for the "identifier" Local Attribute is given in the Table below.

<xs:attribute name="identifier" use="required" type="IdentifierDType" />


The XSD description for the "sequenceIndex" Local Attribute is given in the Table below.

<xs:attribute name="sequenceIndex" use="optional" type="xs:integer" />


The XSD description for the "datestamp" Local Attribute is given in the Table below.

<xs:attribute name="datestamp" use="required" type="DateTimeDType" />


The XSD description for the "sessionStatus" Local Attribute is given in the Table below.

<xs:attribute name="sessionStatus" use="required">
    <xs:simpleType>
        <xs:restriction base="xs:string">
            <xs:enumeration value="final" />
            <xs:enumeration value="initial" />
            <xs:enumeration value="pendingExternalScoring" />
            <xs:enumeration value="pendingResponseProcessing" />
            <xs:enumeration value="pendingSubmission" />
        </xs:restriction>
    </xs:simpleType>
</xs:attribute>


The XSD description for the "responseVariable" Local Element is given in the Table below.

Table - XSD description for the "responseVariable/ItemResultDType" Local Element.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Diagram
Type	ResponseVariableDType
Properties	Content complex MinOccurs 1 MaxOccurs 1 Mixed false
Model	correctResponse{0..1}, candidateResponse{1..1}
Attributes	QName Type Inherited Scope Use Default identifier IdentifierDType No Local Required - cardinality [ Enumeration ] No Local Required - baseType [ Enumeration ] No Local Optional - choiceSequence List of IdentifierListDType No Local Optional - scoreStatus [ Enumeration ] No Local Optional - answeredStatus [ Enumeration ] No Local Optional -
Source	<xs:element name="responseVariable" type="ResponseVariableDType" minOccurs="1" maxOccurs="1" />

The XSD description for the "templateVariable" Local Element is given in the Table below.

Table - XSD description for the "templateVariable/ItemResultDType" Local Element.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Diagram
Type	ContextTemplateVariableDType
Properties	Content complex MinOccurs 1 MaxOccurs 1 Mixed false
Model	value{0..*}
Attributes	QName Type Inherited Scope Use Default identifier IdentifierDType No Local Required - cardinality [ Enumeration ] No Local Required - baseType [ Enumeration ] No Local Optional -
Source	<xs:element name="templateVariable" type="ContextTemplateVariableDType" minOccurs="1" maxOccurs="1" />

The XSD description for the "outcomeVariable" Local Element is given in the Table below.

Table - XSD description for the "outcomeVariable/ItemResultDType" Local Element.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Diagram
Type	OutcomeVariableDType
Properties	Content complex MinOccurs 1 MaxOccurs 1 Mixed false
Model	value{0..*}, outcomeInformation{0..1}
Attributes	QName Type Inherited Scope Use Default identifier IdentifierDType No Local Required - cardinality [ Enumeration ] No Local Required - baseType [ Enumeration ] No Local Optional - view Enumerated List of ViewEnumDType No Local Optional - interpretation xs:string No Local Optional - longInterpretation xs:anyURI No Local Optional - normalMaximum xs:double No Local Optional - normalMinimum xs:double No Local Optional - masteryValue xs:double No Local Optional - external-scored [ Enumeration ] No Local Optional - variable-identifier-ref UniqueIdentifierRefDType No Local Optional -
Source	<xs:element name="outcomeVariable" type="OutcomeVariableDType" minOccurs="1" maxOccurs="1" />

The XSD description for the "contextVariable" Local Element is given in the Table below.

Table - XSD description for the "contextVariable/ItemResultDType" Local Element.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Diagram
Type	ContextTemplateVariableDType
Properties	Content complex MinOccurs 1 MaxOccurs 1 Mixed false
Model	value{0..*}
Attributes	QName Type Inherited Scope Use Default identifier IdentifierDType No Local Required - cardinality [ Enumeration ] No Local Required - baseType [ Enumeration ] No Local Optional -
Source	<xs:element name="contextVariable" type="ContextTemplateVariableDType" minOccurs="1" maxOccurs="1" />

The XSD description for the "candidateComment" Local Element is given in the Table below.

Table - XSD description for the "candidateComment/ItemResultDType" Local Element.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Diagram
Type	xs:string
Properties	Content simple MinOccurs 0 MaxOccurs 1
Model	N/A
Attributes	None.
Source	<xs:element name="candidateComment" type="xs:string" minOccurs="0" maxOccurs="1" />

The XSD description for the "support" Local Element is given in the Table below.

Table - XSD description for the "support/ItemResultDType" Local Element.

Namespace	http://www.imsglobal.org/xsd/imsqti_result_v3p0
Diagram
Type	SupportDType
Type Hierarchy	EmptyPrimitiveTypeDType ^---SupportDType
Properties	Content simple MinOccurs 0 MaxOccurs unbounded
Model	Empty
Attributes	QName Type Inherited Scope Use Default name xs:NCName No Local Required - assignment [ Enumeration ] No Local Required - value xs:normalizedString No Local Optional - language [ Import ] No Local Optional -
Source	<xs:element name="support" type="SupportDType" minOccurs="0" maxOccurs="unbounded" />
